MAX1840

PRODUCTION

Low-Voltage SIM/Smart-Card Level Translators in µMAX

Low-Voltage, High-Speed, SIM/Smart-Card Level Translator

Data Sheet (Rev. 0) Product Selection Table

Part Models: 2
1ku List Price: Starting From $1.93

Viewing:

Part Details

SIM/Smart Card Level Shifting
+1.4V to +5.5V Controller Voltage Range
+1.7V to +5.5V Card Voltage Range
±10kV ESD Card Socket Protection
Allows Level Translation with DV_CC > V_CC or DV_CC < V_CC
Automatically Shuts Down When Either Supply Is Removed
Card Contacts Actively Pulled Low During Shutdown
1µA Total Quiescent Supply Current
0.01µA Total Shutdown Supply Current
Ultra-Small 10-Pin µMAX Package
Compliant with GSM Test Specifications 11.11 and 11.12

Part Models: 2
1ku List Price: Starting From $1.93

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX1840EUB+	10-MINI_SO-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1840EUB+T	10-MINI_SO-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Nov 13, 2024 - 2361T WAFER FAB
		pcn_2361t
MAX1840EUB+	PRODUCTION
MAX1840EUB+T	PRODUCTION
Sep 19, 2018 - 1753N ASSEMBLY
		pcn_1753n
MAX1840EUB+	PRODUCTION
MAX1840EUB+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Hardware Ecosystem

Parts	Product Life Cycle	Description
Regulated Step-Up Charge Pumps 1
MAX1686	PRODUCTION	3V to 5V Regulating Charge Pumps for SIM Cards
SIM Interface 2
MAX1740	Obsolete	SIM/Smart-Card Level Translators in µMAX
MAX1741	Obsolete	SIM/Smart-Card Level Translators in µMAX
