MAX17613A

PRODUCTION

4.5V to 60V, 3A Current-Limiter with OV, UV, and Reverse Protection

Industry's Most Integrated OCP and OVP Solution with Robust Reverse Current Blocking Capability

Data Sheet (Rev. 1) Product Selection Table

Part Models: 2
1ku List Price: Starting From $3.08

Viewing:

Part Details

Robust Protection Reduces System Downtime
- Wide Input-Supply Range of +4.5V to +60V
- Hot Plug-in Tolerant without TVS up to 35V Input Supply
- Negative Input Tolerance up to -65V
- Low R_ON 130m Ω (typ)
- Reverse Current-Blocking Protection
- Thermal Overload Protection
- Programmable Startup Blanking Time
- Extended -40°C to +125°C Temperature Range
- MAX17613A Enables OV, UV, and Reverse Voltage Protection
- MAX17613B Enables OV and UV Protection
- MAX17613C Enables Reverse Voltage Protection
Flexible Design Options Enable Reuse and Less Requalification
- Adjustable OVLO and UVLO Thresholds
- Programmable Forward Current Limit: 0.15A to 3A with ±3.5% Accuracy
- Accuracy Over Full Temperature Range
- Programmable Overcurrent Fault Response: Autoretry, Continuous, and Latchoff Modes
- Smooth Current Transitions
Saves Board Space and Reduces External BOM Count
- 20-Pin, 4mm x 4mm, TQFN-EP Package
- Integrated FETs
UL 2367 Recognized, File No. E211395
IEC 62368-1 Certified

Part Models: 2
1ku List Price: Starting From $3.08

Documentation

Data Sheet 1

MAX17613A-MAX17613C: 4.5V to 60V, 3A Current-Limiter with OV, UV, and Reverse Protection Data Sheet (Rev.1) 02/07/2022

Technical Articles 1

Complete System Power Protection Design Guide 04/02/2020

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX17613AATP+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX17613AATP+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.

Hardware Ecosystem

Parts	Product Life Cycle	Description
Surge Stopper, Overvoltage, and Overcurrent Protection 1
MAX17608	PRODUCTION	4.5V to 60V, 1A Current Limiter with OV, UV, and Reverse Protection

Tools & Simulations

LTspice 1

MAX17613A - Power Monitor, Control, and Protection

Models for the following parts are available in LTspice:

MAX17613A
MAX17613B
MAX17613C

LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits.

Evaluation Kits

Evaluation Kit for the MAX17613A 4.5V to 60V, 3A Current-Limiter with OV, UV and Reverse Protection

Buy Now View Details

Features and Benefits

4.5V to 40V Operating Voltage Range (Remove the TVS Diode to Extend the Operating Voltage Range up to 60V)
Features a 40V TVS Diode (D1) across the Input and Schottky Diode across the Output Terminals
Evaluates Undervoltage-Lockout (UVLO), Overvoltage-Lockout (OVLO), Three Current-Limit Types, and Current-Limit Threshold
UVLO Programmed to 4.5V
OVLO Programmed to 36V
Jumper-Configurable Current-Limit
Jumper-Configurable Current-Limit Type
Programmable Startup Blanking Time
Features Fault Indication Signals (Activ-Low UVOV, Acrive-Low FLAG)
Proven PCB Layout
Fully Assembled and Tested

Product Details

The MAX17613AEVKIT# evaluation kit (EV kit) is a fully assembled and tested circuit board that demonstrates the MAX17613A 4.5V to 60V, 3A, overvoltage (OV), undervoltage (UV) protector with forward current limit and reverse current block in a 20-pin TQFN-EP package. The EV kit can be configured to demonstrate adjustable overvoltage, undervoltage, three current-limit types (Autoretry, Continuous, and Latchoff) with different currentlimit thresholds (from 0.15A to 3A). For more details about the IC benefits and features, refer to the MAX17613 IC data sheet.

Applications

Condition Monitoring
Factory Sensors
Industrial Applications such as PLC, Control Network Modules, Battery-Operated Modules
Process Instrumentation
Sensor Systems
Weighing and Batching Systems

Resources

MAX17613AEVKIT ODB File - Design Files
3.76 M

Evaluation Kit for the MAX17613B 4.5V to 60V, 3A, OV, UV Protector with Forward Current Limit

Buy Now View Details

Features and Benefits

4.5V to 40V Operating Voltage Range (Remove the TVS Diode to Extend the Operating Voltage Range up to 60V)
Features a 40V TVS Diode (D1) across the Input and Schottky Diode across the Output Terminals
Evaluates Undervoltage-Lockout (UVLO), Overvoltage-Lockout (OVLO), Three Current-Limit Types, and Current-Limit Threshold
UVLO Programmed to 4.5V
OVLO Programmed to 36V
Jumper-Configurable Current-Limit
Jumper-Configurable Current-Limit Type
Programmable Startup Blanking Time
Features Fault Indication Signals (Active-Low UVOV, Active-Low FLAG)
Proven PCB Layout
Fully Assembled and Tested

Product Details

The MAX17613BEVKIT# evaluation kit (EV kit) is a fully assembled and tested circuit board that demonstrates the MAX17613B 4.5V to 60V, 3A, overvoltage (OV), undervoltage (UV) protector with forward current limit in a 20-pin TQFN-EP package. The EV kit can be configured to demonstrate adjustable overvoltage, undervoltage, three current-limit types (Autoretry, Continuous, Latchoff), and different current-limit thresholds (from 0.15A to 3A). For more details about the IC benefits and features, refer to the MAX17613 IC data sheet.

Applications

Condition Monitoring
Factory Sensors
Industrial Applications such as PLC, Control Network Modules, Battery-Operated Modules
Process Instrumentation
Sensor Systems
Weighing and Batching Systems

Resources

MAX17613BEVKIT ODB File - Design Files
3.63M

Evaluation Kit for the MAX17613C 4.5V to 60V, 3A, Reverse-Voltage Protector with Forward Current Limit

Buy Now View Details

Features and Benefits

4.5V to 40V Operating Voltage Range (Remove the TVS Diode to Extend the Operating Voltage Range up to 60V)
Features a 40V TVS Diode (D1) across the Input and Schottky Diode across the Output Terminals
Evaluates Three Current-Limit Types and Current-Limit Threshold
Jumper-Configurable Current-Limit
Jumper-Configurable Current-Limit Type
Programmable Startup Blanking Time
Features Fault Indication Signals (Active-Low FWD, Active-Low REV)
Proven PCB Layout
Fully Assembled and Tested

Product Details

The MAX17613CEVKIT# evaluation kit (EV kit) is a fully assembled and tested circuit board that demonstrates the MAX17613C 4.5V to 60V, 3A, reverse-voltage protector with forward current limit and reverse current block in a 20-pin TQFN-EP package. The EV kit can be configured to demonstrate three current-limit types (Autoretry, Continuous, Latchoff) and different current-limit thresholds (from 0.15A to 3A). For more details about the IC benefits and features, refer to the MAX17613 IC data sheet.

Applications

Condition Monitoring
Factory Sensors
Industrial Applications such as PLC, Control Network Modules, Battery-Operated Modules
Process Instrumentation
Sensor Systems
Weighing and Batching Systems
