MAX34417

PRODUCTION

SMBus Four-Channel Very Wide Dynamic Range Power Accumulator

Achieve Longer Battery Life in Mobile Devices

Data Sheet (Rev. 4) Product Selection Table
Part Models
2
1ku List Price
Starting From $5.07
Viewing:

Part Details

  • Enables Code Optimization to Minimize Power Consumption in Portable Platforms
    • Four Power Monitors with Wide 86dB Dynamic Range
    • Measures Both Current and Voltage
    • Low Power Consumption
    • Reduced Power Consumption in Slow Accumulation Mode
    • Power-Down Mode
  • Minimizes Processor Overhead with Autonomous Operation
    • Per Channel 56-Bit Power Accumulators Capture 4.55 Hours of Data at 1024 Samples per Second
    • Per Channel 14-Bit Voltage Registers
  • High-Integration Solution Minimizes Parts Count, PCB Space, and BOM Cost
    • Wide Current Common-Mode Range of 0.5V to 20V
    • Low Full-Scale, Current-Sense Voltage of 100mV
    • As low as 5μV Current-Sense Voltage
    • I2C/SMBus Interface with Bus Timeout
    • Temperature Range: -40°C to +85°C
    • Small, 2mm x 2mm Footprint Wafer-Level Package (WLP) with 16 Bumps at 0.4mm Pitch
  • Ease of Development
    • Evaluation Kit with Advanced GUI Available
MAX34417
SMBus Four-Channel Very Wide Dynamic Range Power Accumulator
MAX34417 Block Diagram MAX34417 Pin Configuration
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project
Ask a Question

Documentation

Data Sheet 1

User Guide 1

Application Note 2

Design Note 1

Evaluation Design File 1

Learn More
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project

Hardware Ecosystem

Parts Product Life Cycle Description
Current Sense Amplifiers 1
MAX34407
PRODUCTION SMBus 4-Channel Wide Dynamic Range Power Accumulator
Modal heading
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project

Tools & Simulations

Software Development 4

IBIS Model 1

Evaluation Kits

eval board
schematic 1
MAX34417EVKIT

Evaluation Kit for the MAX34417

Buy Now View Details

Features and Benefits

  • Easy Evaluation of the MAX34417
  • USB-12C/SMBus Interface
  • PC, Laptop, or Tablet with Windows XP®, Windows® 7, 8, and 10 Compatible Software
  • Proven PCB Layout
  • Fully Assembled and Tested

Product Details

The MAX34417 evaluation kit (EV kit) provides the hardware and software graphical user interface (GUI) necessary to evaluate the MAX34417 SMBus Four-Channel, High Dynamic Range Power Accumulator. The EV Kit includes a MAX34417ENE+ installed EV board, as well as a micro- USB cable to communicate with a PC.

Applications

  • Servers
  • Smartphones
  • Tablets
  • Ultra Notebooks
MAX34417EVKIT
Evaluation Kit for the MAX34417
MAX34417EVKIT: Board Photo
