MAX20484

RECOMMENDED FOR NEW DESIGNS

Three- to Five-Input Power-System Monitor with Clock Monitor and Watchdog

A Complete ASIL D Compliant SoC Power-System Monitor with up to Five Voltage Monitor Inputs

Data Sheet (Rev. 3) Product Selection Table
Part Models
4
1ku List Price
Starting From $1.87
Viewing:

Part Details

  • Small Solution
    • 2.35V to 5.60V Operating Supply Voltage
    • Only One External Component Required
    • 150µA Operating Current
    • 8µA Power-Down Mode
    • Universal Channel Configurations
  • High Precision
    • Selectable 102.5% to 110% OV Monitors
    • Selectable 97.5% to 90% UV Monitors
    • ±0.8% Accuracy with 0.5% Step Size
    • ASIL D Compliance
  • Highly Integrated
    • Five Fixed-Voltage Monitoring Inputs
    • Clock/Fault Monitor Input (25kHz to 50MHz)
    • Power-Sequencing Recording
    • Simple or Challenge/Response Windowed Watchdog
    • Fault Recording
    • CRC on I2C Interface
    • Programmable I2C Address
    • OTP Configuration with Error-Correcting Code and Reload Functionality
    • Two Independently Programmable Active-Low RESET Pins
  • 3mm x 3mm, 16-Pin, Side-Wettable TQFN-EP
  • AEC-Q100 Qualified
  • -40°C to +125°C Operating Temperature
MAX20484
Three- to Five-Input Power-System Monitor with Clock Monitor and Watchdog
MAX20484 Simplified Block Diagram
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project
Ask a Question

Documentation

Data Sheet 1

Request an NDA

Complete documentation is available upon completion of a Non-Disclosure Agreement (NDA).

Request an NDA
Learn More
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project

Evaluation Kits

MAX20484EVKIT

Evaluation Kit for the MAX20484 Voltage Monitor with Watchdog and Clock Monitor

Buy Now View Details

Features and Benefits

  • Easy to Reach Test Points for Debugging
    • Pre and Post Filter Connections
    • Input Jumpers for Logic Probe Connections
  • I2C Communication Header Allows for Flexible Interfacing
  • Maxim PICO2MINIQ# Communication Board
  • Used with the MAX20484 Graphical User Interface
  • Fully Assembled and Tested

Product Details

The MAX20484 evaluation kit (EV kit) provides a platform to evaluate the performance and features of the MAX20484 Power System Monitor. The voltage monitoring accuracy, watchdog, power sequence recorder, and clock monitoring of the MAX20484 are fully demonstrable through the evaluation board hardware and the accompanying software. Figure 1 shows the block diagram of the EV kit.

The I2C communication is controlled using a Universal Serial Bus (USB) to I2C bridge that provides an interface between the IC and Graphical User Interface (GUI) which provides access to the MAX20484’ register set for configuration and status reporting.

Applications

  • ADAS
  • Autonomous Driving Processing Systems
  • Power System Supervision and MCU/SoC Monitoring
  • Remote Sensor Modules

MAXPICO2MINIQ

Evaluation Kit for the MAX20484 Voltage Monitor with Watchdog and Clock Monitor

Buy Now View Details

Features and Benefits

  • Easy to Reach Test Points for Debugging
    • Pre and Post Filter Connections
    • Input Jumpers for Logic Probe Connections
  • I2C Communication Header Allows for Flexible Interfacing
  • Maxim PICO2MINIQ# Communication Board
  • Used with the MAX20484 Graphical User Interface
  • Fully Assembled and Tested

Product Details

The MAX20484 evaluation kit (EV kit) provides a platform to evaluate the performance and features of the MAX20484 Power System Monitor. The voltage monitoring accuracy, watchdog, power sequence recorder, and clock monitoring of the MAX20484 are fully demonstrable through the evaluation board hardware and the accompanying software. Figure 1 shows the block diagram of the EV kit.

The I2C communication is controlled using a Universal Serial Bus (USB) to I2C bridge that provides an interface between the IC and Graphical User Interface (GUI) which provides access to the MAX20484’ register set for configuration and status reporting.

Applications

  • ADAS
  • Autonomous Driving Processing Systems
  • Power System Supervision and MCU/SoC Monitoring
  • Remote Sensor Modules
MAX20484EVKIT
Evaluation Kit for the MAX20484 Voltage Monitor with Watchdog and Clock Monitor
MAXPICO2MINIQ
Evaluation Kit for the MAX20484 Voltage Monitor with Watchdog and Clock Monitor
