MAX17552

PRODUCTION

60V, 100mA, Ultra-Small, High-Efficiency, Synchronous Step-Down DC-DC Converter with 22μA No-Load Supply Current

60V, Low I_Q Synchronous Buck Regulator Enables High Efficiency

Data Sheet (Rev. 7) Product Selection Table

Part Models: 4
1ku List Price: Starting From $1.44

Viewing:

Part Details

Eliminates External Components and Reduces Total Cost
- No Schottky—Synchronous Operation for High Efficiency and Reduced Cost
- Internal Compensation
- Fixed Internal 5.1ms or Programmable Soft-Start
- All-Ceramic Capacitors, Ultra-Compact Layout
Reduces Number of DC-DC Regulators to Stock
- Wide 4V to 60V Input Voltage Range
- Adjustable 0.8V to 0.9 x V_IN Output Voltages
- Delivers Up to 100mA Load Current
- 100kHz to 2.2MHz Adjustable Switching Frequency Range with External Clock Synchronization
- Configurable Between PFM and Forced-PWM Modes
Reduces Power Dissipation
- 22µA No Load Supply Current
- Peak Efficiency > 90%
- PFM Feature for High Light-Load Efficiency
- 1.2µA (typ) Shutdown Current
Operates Reliably in Adverse Industrial Environments
- Peak Current-Limit Protection
- Built-In Output-Voltage Monitoring with Open-Drain Active-Low RESET Pin
- Programmable EN/UVLO Threshold
- Complies with CISPR32 (EN55032) Class B Conducted and Radiated Emissions
- Monotonic Startup into Prebiased Output
- Overtemperature Protection
- Wide -40°C to +125°C Ambient Operating Temperature Range / -40°C to +150°C Junction Temperature Range

Part Models: 4
1ku List Price: Starting From $1.44

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX17552ATB+	Thin Dual Flatpack No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX17552ATB+T	Thin Dual Flatpack No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX17552AUB+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX17552AUB+T	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Feb 14, 2022 - 2195 DESIGN,WAFER FAB
		pcn_2195
MAX17552ATB+	PRODUCTION
MAX17552ATB+T	PRODUCTION
MAX17552AUB+	PRODUCTION
MAX17552AUB+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Hardware Ecosystem

Parts	Product Life Cycle	Description
Internal Power Switch Buck Regulators 1
MAX15062	PRODUCTION	60V, 300mA, Ultra-Small, High-Efficiency, Synchronous Step-Down DC-DC Converters

Tools & Simulations

EE-Sim Power® Tools 1

The EE-Sim DC-DC Converter Tool uses your requirements to quickly create a complete power design including a schematic, BOM with commercially available parts, and time and frequency domain simulations. Your customized schematic can be downloaded for further analysis in the standalone EE-Sim OASIS Simulator, featuring SIMPLIS and SIMetrix SPICE engines.

Start EE-Sim Now

SIMPLIS Models 1

MAX17552 SIMPLIS Schematic

Evaluation Kits

Evaluation Kit for the MAX17552 (TDFN) in 5V Output Voltage Applications

Buy Now View Details

Features and Benefits

Wide 6V to 60V Input Voltage Range
5V Output, 100mA Continuous Current
93% Peak Efficiency
26μA No Load Supply Current
Enable/UVLO Input, Resistor-Programmable UVLO Threshold
Internal or Programmable Soft-Start
Selectable PWM and PFM Modes of Operation
Open-Drain Active-Low RESET Output
Overcurrent Protection
Overtemperature Protection
Proven PCB Layout
Fully Assembled and Tested

Product Details

The MAX17552 5V evaluation kit (EV kit) (TDFN) is a fully assembled and tested circuit board that demonstrates the performance of the MAX17552 60V, 100mA ultra-small, high-efficiency, synchronous step-down DC-DC converter in a 10-pin TDFN package. The EV kit operates over a wide input-voltage range of 6V to 60V and provides up to 100mA load current at 5V output. It draws only 26µA supply current under no-load conditions (EN/UVLO connected to V_IN). The EV kit is programmed to switch at a frequency of 220kHz and delivers a peak efficiency of 93% with the supplied components. The device is simple to use and easily configurable with minimal external components. It features cycle-by-cycle peak current limit protection, undervoltage lockout, and thermal shutdown.

The EV kit comes installed with the MAX17552ATB+ in a 10-pin (3mm x 2mm) lead(Pb)-free/RoHS-compliant TDFN package.

Applications

4–20mA Current-Loop Powered Sensors
Battery-Powered Equipment
General-Purpose Point-of-Load
High-Voltage LDO Replacement
HVAC and Building Control
Industrial Sensors and Process Control

Resources

MAX17552ATBEVKIT Gerber File - Design Files
6.51M

MAX17552ATBEVKIT Gerber File
6.51M

Evaluation Kit for the MAX17552A (TDFN) in 5V Output Voltage Applications

Buy Now View Details

Features and Benefits

Wide 6V to 60V Input Voltage Range
5V Output, 100mA Continuous Current
93% Peak Efficiency
26µA No Load Supply Current
Enable/UVLO Input, Resistor-Programmable UVLO Threshold
Internal or Programmable Soft-Start
Selectable PWM and PFM Modes of Operation
Open-Drain Active-Low RESET Output
Overcurrent Protection
Overtemperature Protection
Proven PCB Layout
Fully Assembled and Tested

Product Details

The MAX17552AEVKIT# evaluation kit (EV kit) is a fully assembled and tested circuit board that demonstrates the performance of the MAX17552A 60V, 100mA ultra-small, high-efficiency, Himalaya synchronous step-down DC-DC converter in a 10-pin TDFN package. The EV kit operates over a wide input-voltage range of 6V to 60V and provides up to 100mA load current at 5V output. It draws only 26µA supply current under no-load conditions (EN/UVLO connected to V_IN). The EV kit is programmed to switch at a frequency of 220kHz and delivers a peak efficiency of 93% with the supplied components. The device is simple to use and easily configurable with minimal external components. It features cycle-by-cycle peak current limit protection, undervoltage lockout, and thermal shutdown.

The EV kit comes installed with the MAX17552AATB+ in a 10-pin (3mm x 2mm) lead(Pb)-free/RoHS-compliant TDFN package.

Applications

4–20mA Current-Loop Powered Sensors
Battery-Powered Equipment
General-Purpose Point-of-Load
High-Voltage LDO Replacement
HVAC and Building Control
Industrial Sensors and Process Control

Evaluation Kit for the MAX17552 (µMAX) in 5V Output-Voltage Application

Buy Now View Details

Features and Benefits

6V to 60V Input Voltage Range
5V Output, 100mA Continuous Current
93% Peak Efficiency
26µA No-Load Supply Current
EN/UVLO for On/Off Control and Programmable Input Undervoltage Lockout
Programmable Switching Frequency
Internal or Programmable Soft-Start
PFM or Forced-PWM Mode of Operation
Active-Low RESET Output
Peak Current-Limit Protection
Thermal Shutdown
Proven PCB Layout
Fully Assembled and Tested

Product Details

The MAX17552 5V evaluation kit (EV kit) (µMAX^®) is a fully assembled and tested circuit board that demonstrates the performance of the MAX17552 60V, 100mA ultra-small, high-efficiency, synchronous step-down DC-DC converter in a 10-pin µMAX package. The EV kit operates over a wide input voltage range of 6V to 60V and provides up to 100mA load current at 5V output. It draws only 26µA supply current under no-load conditions (EN/UVLO connected to V_IN). The EV kit is programmed to switch at a frequency of 220kHz and delivers a peak efficiency of 93% with the supplied components. The device is simple to use and easily configurable with minimal external components. It features cycle-by-cycle peak current-limit protection, undervoltage lockout and thermal shutdown.

The EV kit comes installed with the MAX17552AUB+ in an 10-pin (3mm x 3mm), lead(Pb)-free/RoHS-compliant µMAX package.
