ADF4113HV

RECOMMENDED FOR NEW DESIGNS

High Voltage Charge Pump, PLL Synthesizer

Data Sheet (Rev. B) Product Selection Table

Part Models: 6
1ku List Price: Starting From $3.06

Viewing:

Part Details

High voltage charge pump (15 V)
2.7 V to 5.5 V power supply
Pin compatible with ADF4110, ADF4111, ADF4112, ADF4113 ADF4106, and ADF4002 synthesizers
200 MHz to 4.0 GHz frequency range
Two selectable charge pump currents
Digital lock detect
Power-down mode
Loop filter design possible with ADIsimPLL™

Part Models: 6
1ku List Price: Starting From $3.06

Documentation

Frequently Asked Question 1

FAQ 03/03/2022

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
ADF4113HVBCPZ	20-Lead LFCSP (4mm x 4mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADF4113HVBCPZ-RL	20-Lead LFCSP (4mm x 4mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADF4113HVBCPZ-RL7	20-Lead LFCSP (4mm x 4mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADF4113HVBRUZ	16-Lead TSSOP	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADF4113HVBRUZ-RL	16-Lead TSSOP	Material Declaration Reliablity Data	Ultra Librarian SamacSys
ADF4113HVBRUZ-RL7	16-Lead TSSOP	Material Declaration Reliablity Data	Ultra Librarian SamacSys
