ADPL62083
推荐新设计使用Low-Power, Supervisory Circuit in 3-Lead SOT23
Low-Power Supervisory Circuit in 3-Lead SOT-23
- 产品模型
- 10
产品详情
- Low Supply Current: 5μA (typ), 6.8μA (max) at 3.6V Over Temperature (+125°C)
- Factory-Set Reset Threshold Options from 1.02V to 4.8V in 50mV/100mV Increments
- Guaranteed Reset Valid to VCC ≥ 1V
- Open-Drain Reset Output
- Power-Supply Transient Immunity
- -40°C to +125°C Operating Temperature Range
The ADPL62083 is a supervisory circuit that monitors voltages from 1.02V to 4.8V using a factory-set reset threshold.
The ADPL62083 features an open-drain, active-low reset output. The reset output asserts and remains asserted for the reset timeout period after the monitored voltage exceeds its threshold.
The ADPL62083 is available in 3-lead SOT23 package. It operates over the -40°C to +125°C temperature range.
APPLICATIONS
- Portable/Battery-Powered and Industrial Equipment
- e-Readers/Tablets
- Smartphones
参考资料
ADI 始终高度重视提供符合最高质量和可靠性水平的产品。我们通过将质量和可靠性检查纳入产品和工艺设计的各个范围以及制造过程来实现这一目标。出货产品的“零缺陷”始终是我们的目标。查看我们的质量和可靠性计划和认证以了解更多信息。
| 产品型号 | 引脚/封装图-中文版 | 文档 | CAD 符号，脚注和 3D模型 |
|---|---|---|---|
| ADPL62083UR16N+ | 3-SOT_23-N/A | ||
| ADPL62083UR16N+T | 3-SOT_23-N/A | ||
| ADPL62083UR29H+ | 3-SOT_23-N/A | ||
| ADPL62083UR29H+T | 3-SOT_23-N/A | ||
| ADPL62083UR30O+ | 3-SOT_23-N/A | ||
| ADPL62083UR30O+T | 3-SOT_23-N/A | ||
| ADPL62083UR31O+ | 3-SOT_23-N/A | ||
| ADPL62083UR31O+T | 3-SOT_23-N/A | ||
| ADPL62083UR44Q+ | 3-SOT_23-N/A | ||
| ADPL62083UR44Q+T | 3-SOT_23-N/A |
这是最新版本的数据手册
