HMC276

Obsolete

HMC276LP4 / HMC276QS24

4 x 2 Switch Matrix SMT, 0.2 GHz to 3.0 GHz

Data Sheet Product Selection Table

Part Models: 4
1ku List Price: price unavailable

Viewing:

Part Details

4 x 2 switch matrix using one IC
4 x 4 switch matrix using two ICs
Integrated 4-bit decoder

Single positive supply: Vdd = 5 V
QFN leadless SMT package: 16 mm²

Suggested Replacement Parts

CMOS 4x2 Switch Matrix SMT, 0.2 - 3.0

Part Models: 4
1ku List Price: price unavailable

Documentation

Data Sheet 2

HMC276LP4 Data Sheet 04/16/2015

HMC276QS24 Data Sheet 04/16/2015

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC276LP4E	24-Lead QFN (4mm x 4mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC276LP4ETR	24-Lead QFN (4mm x 4mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC276QS24E	24-Lead QSOP	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC276QS24ETR	24-Lead QSOP	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Dec 14, 2015 - 15_0026 Discontinuance of Select Hittite Microwave Products (HMC) from Analog Devices
		PDN15_0026_Form Material_Report
HMC276LP4E	Obsolete
HMC276LP4ETR	Obsolete
HMC276QS24E	Obsolete
HMC276QS24ETR	Obsolete
