MAX20010C

量产

汽车应用、单通道、6A降压型转换器

高精度、全集成、同步、6A转换器，具有灵活的DVS

数据手册 (Rev. 10) 产品选型表

产品模型: 24

Viewing:

产品详情

全集成、同步、6A DC-DC转换器，支持小方案尺寸
- 3.0V至5.5V工作电压
高精度电压调节器，适用于应用处理器
- ±2%输出电压精度
- 差分远端电压检测
- I²C控制的0.5V至1.27V输出电压，步长为10mV；或0.625V至1.5875V，步长为12.5mV
- 优异的负载瞬态性能
低噪声特性降低EMI
- 2.2MHz工作频率
- 扩频选项
- 频率同步输入/输出
- 电流模式、强制PWM或跳脉冲工作模式
支持汽车环境的可靠性
- PGOOD输出
- 过热和短路保护
- 20引脚(4mm × 4mm) TQFN封装，带裸焊盘
- -40°C至+125°C工作温度范围
- AECQ-100认证

参考资料

数据手册 1

MAX20010C-MAX20010E: Automotive Single 6A Step-Down Converters Data Sheet (Rev.10) 02/23/2022

ADI 始终高度重视提供符合最高质量和可靠性水平的产品。我们通过将质量和可靠性检查纳入产品和工艺设计的各个范围以及制造过程来实现这一目标。出货产品的“零缺陷”始终是我们的目标。查看我们的质量和可靠性计划和认证以了解更多信息。

产品型号	引脚/封装图-中文版	文档	CAD 符号，脚注和 3D模型
MAX20010CATPB/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPB/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPD/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPD/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPE/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPE/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPF/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPF/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPJ/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPJ/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPL/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPL/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPM/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPM/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPQ/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPQ/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPU/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPU/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPW/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPW/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPX/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPX/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPY/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX20010CATPY/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data	Ultra Librarian SamacSys

产品型号	产品生命周期	PCN

4月 16, 2021 - 2142 ASSEMBLY
		pcn_2142
MAX20010CATPD/V+	量产
MAX20010CATPD/V+T	量产
MAX20010CATPE/V+	量产
MAX20010CATPE/V+T	量产
MAX20010CATPJ/V+	量产
MAX20010CATPL/V+	量产
MAX20010CATPL/V+T	量产
MAX20010CATPM/V+	量产
MAX20010CATPM/V+T	量产
MAX20010CATPQ/V+	量产
MAX20010CATPQ/V+T	量产
MAX20010CATPU/V+	量产
MAX20010CATPW/V+	量产
MAX20010CATPX/V+	量产
3月 24, 2021 - 1994B DESIGN,WAFER FAB
		pcn_1994b
MAX20010CATPD/V+	量产
MAX20010CATPD/V+T	量产
MAX20010CATPE/V+	量产
MAX20010CATPE/V+T	量产
MAX20010CATPJ/V+	量产
MAX20010CATPL/V+	量产
MAX20010CATPL/V+T	量产
MAX20010CATPM/V+	量产
MAX20010CATPM/V+T	量产
MAX20010CATPQ/V+	量产
MAX20010CATPQ/V+T	量产
MAX20010CATPU/V+	量产
MAX20010CATPW/V+	量产
MAX20010CATPX/V+	量产
9月 29, 2020 - 1994 WAFER FAB
		pcn_1994
MAX20010CATPD/V+	量产
MAX20010CATPE/V+T	量产
MAX20010CATPJ/V+	量产
MAX20010CATPQ/V+	量产

这是最新版本的数据手册

工具及仿真模型

EE-Sim Power®工具 1

EE-Sim DC-DC转换器工具可根据您的要求快速创建完整的电源设计，包括原理图、BOM（采用市售部件）、时域和频域仿真。您可以下载自定义原理图，在独立EE-Sim OASIS仿真器中进一步分析，其中采用SIMPLIS和SIMetrix SPICE引擎。

立即开始EE-Sim

评估套件

MAX20010C/MAX20010D 评估套件

立即购买更多内容

特性和优点

差分远端电压检测
3V至5.5V输入电源范围
I²C控制的0.5V至1.5875V输出电压范围
2.2MHz工作频率
±2%输出电压精度
电源就绪输出
电流模式、强制PWM或跳脉冲工作模式
经过验证的PCB布局
完全装配并经过测试

产品详情

MAX20010评估套件(EV kit)用于演示MAX20010汽车应用单通道6A降压型转换器。评估套件工作在3V至5.5V输入范围，输出设置为1V，高达6A负载电流。
