MAX17852

• 为评估MAX17852的特性和功能提供了一个便利的平台
• 在多功能的GUI界面中进行功能评估
• 即插即用型架构可加快系统原型制作
• 驱动和检测引脚接头实现精密的测量评估
• 内置用于电池仿真的串联电阻
• 经过验证的PCB布局
• 装配完成且经过测试

MAX17852评估套件（EV套件）用于演示MAX17852 14通道高压智能传感器数据采集接口IC的特性和功能。该评估套件与MAX17841B评估套件相结合，可与主机PC建立通信。建立通信后，即可通过主机PC上的评估套件图形用户界面(GUI)对MAX17852评估套件进行控制。该GUI与Windows XP^®、Windows Vista^®、Windows^® 7和Windows 10兼容，可通过您当地的Maxim Integrated销售办事处获取。注：本数据手册中提及MAX17841的内容也与MAX17841B相关。

MAX17852评估套件设计提供了一个便利的平台，用于评估该IC的特性和功能以及电气参数。借助该评估套件中的垂直通信连接器（P2、P3、P5和P6）和卡扣式锁定电池组连接器，用户可以快速构建和评估最多包含32个菊花链器件的系统。

应用

• 48V系统
• 电池备用系统(UPS)
• 电池供电工具
• 电动自行车
• 电动汽车(EV)
• 高压电池堆
• 混合动力汽车(HEV)
• 超级电容系统

• 3 to 14 cell voltage measurement with ±2mV accuracy at 5°C to 40°C
• Supports flexi pack configuration
• Pack current measurement using external current sense resistor
• Passive cell balancing up to 300mA with internal switch with odd or even cell balancing scheme (single cell or group)
• Auto cell balancing configuration with undervoltage (UV) threshold and timer options
• Manual cell balancing configuration
• Four configurable auxiliary inputs for temperature, voltage, or GPIO
• Internal die temperature measurement
• Individually configurable safety alert
• Overvoltage (OV), undervoltage, overtemperature and undertemperature faults
• One cell-mismatch alert
• Selectable universal asynchronous receiver- transmitter (UART) or serial peripheral interface (SPI)
• UART configurations with packet error checking (PEC)
• Dual UART configuration with redundancy
• Single UART configuration
• Single-side component placement
• Compatible with MAX17852EVKIT software along with MINIQUSB board

Up to 112 cell voltage measurement with ±2mV accuracy at 5°C to 40°C.

Supports flexi-pack configuration.

Pack-current measurement using external current-sense resistor.

Passive cell balancing up to 300mA with internal switch, with odd/even cell balancing scheme (single cell or group).

• Auto cell balancing configuration with undervoltage (UV) threshold and timer options.
• Manual cell balancing configuration.

Four configurable auxiliary inputs for temperature, voltage, or GPIO.

Internal die temperature measurement. Individually configurable safety alert.

• Overvoltage (OV), undervoltage (UV), overtemperature, and undertemperature faults.
• One cell mismatch alert.

Selectable Universal Asynchronous Receiver-Transmitter (UART) or Serial Peripheral Interface (SPI).

UART configurations with Packet Error Checking (PEC).

• Dual UART configuration with redundancy.
• Single UART configuration.

Single-side component placement.

Compatible with MAX17852EVKIT software along with MINIQUSB board.

• 6 to 28 cell (minimum 3 cells per pack) voltage measurement with ±2mV accuracy at 5°C to 40°C
• Supports flexi pack configuration
• Pack current measurement using external current sense resistor
• Passive cell balancing up to 300mA with internal switch using odd or even cell balancing scheme (single cell or group)

  • Auto cell balancing configuration with undervoltage (UV) threshold and timer options
  • Manual cell balancing configuration
• Configurable auxiliary inputs

  • Six aux channels for the MAX17853, all configured for temperature measurement
  • Four aux channels for the MAX17852, configured for I²C and GPIO
• Internal die temperature measurement
• Individually configurable safety alert

  • Overvoltage (OV), undervoltage, overtemperature and under temperature faults
  • One cell mismatch alert
• Selectable universal asynchronous receiver-transmitter (UART) or serial peripheral interface (SPI)
• ART configurations with packet error checking (PEC)

  • Dual UART configuration with redundancy
  • Single UART configuration
• Compatible with the MAX17852 and MAX17853 EV Kit software along with MINIQUSB board
