ADP176x-EVALZ
ADP1761/ADP1762/ADP1763 Evaluation Board
トップへ
製品概要
機能と利点
- Input voltage range: 1.1 V to 1.98 V
- Output current range
– ADP1761: 0 mA to 1 A
– ADP1762: 0 mA to 2 A
– ADP1763: 0 mA to 3 A - Output voltage accuracy: ±1.5%
- Operating temperature range: −40°C to +125°C
製品概要
The ADP1761, ADP1762, and ADP1763 evaluation boards demonstrate the functionality of the ADP1761, ADP1762, and ADP1763 series of linear regulators.Simple device measurements, such as line and load regulation, dropout voltage, and ground current, are demonstrated with only a single voltage supply, a voltmeter, an ammeter, and load resistors.
For full details on the ADP1761, ADP1762, and ADP1763 line regulators, see the ADP1761, ADP1762, and ADP1763 data sheets, which should be consulted in conjunction with the user guide, UG-954, when using this evaluation board.
