MAX1730

PRODUCTION

50mA, Regulated, Step-Down Charge Pump for 1.8V or 1.9V Logic

Data Sheet (Rev. 0) Product Selection Table

Part Models: 2
1ku List Price: Starting From $1.72

Viewing:

Part Details

> 85% Peak Efficiency
50mA Guaranteed Output Current
Dual-Mode 1.8V or 1.9V Output
±3% Output Voltage Accuracy
Up to 2MHz Operating Frequency
Small 0.22µF Capacitors
No Inductor Required
2.7V to 5.5V Input Voltage Range
Output Disconnects from Input in Shutdown Mode
Small 10-Pin µMAX Package (1.09mm max height)

Part Models: 2
1ku List Price: Starting From $1.72

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX1730EUB+	10-MINI_SO-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX1730EUB+T	10-MINI_SO-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Sep 19, 2018 - 1753N ASSEMBLY
		pcn_1753n
MAX1730EUB+	PRODUCTION
MAX1730EUB+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.
