HMC1119

RECOMMENDED FOR NEW DESIGNS

0.25 dB LSB, 7-Bit, Silicon Digital Attenuator, 0.1 GHz to 6.0 GHz

Data Sheet (Rev. C) Product Selection Table

Viewing:

Part Details

Attenuation range: 0.25 dB LSB steps to 31.75 dB
Low insertion loss:
- 1.1 dB at 1.0 GHz
- 1.3 dB at 2.0 GHz
Typical step error: less than ±0.1 dB
Excellent attenuation accuracy: less than ±0.2 dB
Low phase shift error: 6° phase shift at 1.0 GHz
Safe state transitions
High linearity
- 1 dB compression (P1dB): 31 dBm typical
- Input third-order intercept (IP3): 54 dBm typical
RF settling time (0.05 dB final RF output): 250 ns
Single supply operation: 3.3 V to 5.0 V
ESD rating: Class 2 (2 kV human body model (HBM))
24-lead, 4 mm × 4 mm LFCSP package: 16 mm²

Documentation

This is the most up-to-date revision of the Data Sheet.

Tools & Simulations

IBIS Model 1

HMC1119LP4ME IBIS Model

S-Parameter 1

HMC1119 S-Parameters

ADIsimRF

ADIsimRF is an easy-to-use RF signal chain calculator. Cascaded gain, noise, distortion and power consumption can be calculated, plotted and exported for signal chains with up to 50 stages. ADIsimRF also includes an extensive data base of device models for ADI’s RF and mixed signal components.
