RF Front-End ICs

RF Front-End ICs

Analog Devices offers RF Front-End ICs for phased array antenna solutions. These RF Front-End ICs are placed right at the antenna element and can quickly switch between transmit and receive functions in radar applications. The power amplifier on the transmit side is highly efficient operating in short pulse durations. The low noise amplifier on the receive side has a low noise figure with high linearity so that it won’t distort the incoming return signal. The RF Front-End IC also incorporates a high performance switch to toggle between the transmit and receive paths. Highly integrated planar phased array antennae need small form factor solutions, and Analog Devices has integrated the switch, low noise amplifier, and power amplifier into a small surface mount package as well as the decoupling capacitors, providing an optimal solution.

Analog Devices offers RF Front-End ICs for phased array antenna solutions. These RF Front-End ICs are placed right at the antenna element and can quickly switch between transmit and receive functions in radar applications. The power amplifier on the transmit side is highly efficient operating in short pulse durations. The low noise amplifier on the receive side has a low noise figure with high linearity so that it won’t distort the incoming return signal. The RF Front-End IC also incorporates a high performance switch to toggle between the transmit and receive paths. Highly integrated planar phased array antennae need small form factor solutions, and Analog Devices has integrated the switch, low noise amplifier, and power amplifier into a small surface mount package as well as the decoupling capacitors, providing an optimal solution.

View All Parts in Subcategory

Massive MIMO Receiver Front-Ends ICs

ADI’s Receiver Front-End ICs for 5G massive multiple-input multiple-output (MIMO) applications incorporate high power switching and low noise amplification in compact size. Advanced circuit architecture minimizes the need for external components, creating an integrated front-end solution. The devices feature single supply operation and interface for CMOS control signals, which makes them easy to use in multi-channel hardware designs with repeatable performance over the complete system. ADI provides reference design, measured s-parameters and evaluation boards from stock that gives the system engineers the advantage to reduce their development times.

Phased Array RF Front-End ICs (LNA, PA, Switch)

Analog Devices offers integrated Front End ICs for phased array antennas, providing a more compact solution which is more easily deployed. The Front End ICs can be paired with Analog Devices beamforming ICs (such as ADAR1000) for analog beamforming antenna or transceiver / data converter products for digital beamforming antenna. These Front End ICs integrate the Power Amplifier (PA), Low Noise Amplifier (LNA), and transmit / receive Switch (SW) that mate with the antenna element for radar applications. The compact size and simplification of these products enable flat panel array technology that would have previously been very difficult with conventional standard single function products. These products not only contain the PA/LNA/SW but all of the passive circuitry needed for utilizing these parts. Some of these products may be used in CW applications such as datalinks as well as pulsed radar applications.

RF Front-End ICs

Subcategories

Massive MIMO Receiver Front-Ends ICs

Phased Array RF Front-End ICs (LNA, PA, Switch)
