MAX20313

• 工作电压范围：2.5V至5.5V
• 电源、使能和标志LED读数
• 经过验证的PCB布局
• 装配完成且经过测试

MAX20313评估套件（EV套件）是一块装配完成且经过测试的电路板，用于演示MAX20313 500mA至6A可调限流开关器件。该评估套件已安装MAX20313EWC+。该评估板还可用于评估MAX20314、MAX20315和MAX20316。

应用

• 数据调制解调器卡
• 便携式媒体播放器
• 手机中的RF功率放大器
• SDXC卡电源保护
• USB端口
• UTCA/ATCA平台

• GMSL2 prototyping system supporting the NVIDIA Jetson™ SoCs
• On-board MAX96724 that allows 4x GMSL2/1 camera inputs that allows for camera module bring-up, debug, and video streaming
• On-board MAX96717 that can be used for camera emulation and head-unit debug
• Enables development of GMSL applications with NVIDIA Jetson™ SoC
• SAMTEC connector that allows connection of any GMSL DPHY EV Kit to the NVIDIA Jetson™
• Additional inputs: USB, Ethernet, PCIe, and microSD card

The AD-GMSL522-SL is a GMSL-enabled NVIDIA Jetson Xavier™ NX-based carrier board and software solution that allows for simple camera to display conversion. This solution creates a scalable, user friendly, GMSL platform for receiving and transmitting data over a gigabit multimedia serial link (GMSL). The platform enables demonstrations and ecosystem development by serving as a hardware platform for software development.

The AD-GMSL522-SL supports two forms of camera input -- either straight CSI data coming through a SAMTEC connector, or via camera modules using GMSL2 or GMSL1 technology to connect to the on-board MAX96724 via COAX connectors. GMSL evaluation kits or any camera utilizing the standard 15- or 22-pin Raspberry Pi connector can be connected here using the AD-GMSLCAMRPI-SL adapter board.

The AD-GMSL522-SL package includes software tools to enable customers in their development of GMSL applications. Among these tools are modified L4T kernels that support certain camera modules and documentation that allows any user to update these kernels for their specific hardware needs.

The design incorporates the MAX96724GTN/VY+ Quad tunneling GMSL2/1 to CSI-2 deserializer and MAX96717GTJ/VY+ CSI-2 to GMSL2 serializer and provides a reliable platform to evaluate high-bandwidth GMSL.

There are two system options available for purchase: the AD-GMSL522-SL which is the base carrier board and does not include the NVIDIA SoM, and the AD-GMSL522-SOM-SL which is the carrier board including the NVIDIA Jetson Xavier™ NX SoM.

APPLICATIONS

• ADAS Camera Solutions
• Sensor Fusion ECU
• Driver and Occupant Monitoring
• In-cabin Infotainment
