MAX1462

低电压、低功耗、16位智能ADC

低电压、低功耗16位数据采集系统，可理想用于功耗敏感设备

Viewing:

产品详情

Low-Voltage Operation (2.4V to 3.6V)
Low-Noise, 310µA Single-Chip Sensor Signal Conditioning
High-Precision Front End Resolves < 400nV of Differential Input Signal
On-Chip DSP and EEPROM Provide Digital Correction of Sensor Errors
16-Bit Signal Path Compensates Sensor Offset and Sensitivity and Associated Temperature Coefficients
12-Bit Parallel Digital Output
Analog Output
Compensates a Wide Range of Sensor Sensitivity and Offset
Single-Shot Automated Compensation Algorithm—No Iteration Required
Built-In Temperature Sensor
Three-State, 5-Wire Serial Interface Supports High-Volume Manufacturing

这是最新版本的数据手册

部分模型	产品周期	描述
ADC和DAC组合 1
MAX1358B	量产	16位数据采集系统，带有ADC、DAC、UPIO、RTC、电压监测器和温度传感器
产品 1
MAX1359B		16位数据采集系统，带有ADC、DAC、UPIO、RTC、电压监测器和温度传感器
单通道模数转换器 2
MAX11213	量产	16位、单通道、超低功耗、Σ-Δ ADC，具有可编程增益和GPIO
MAX11205	量产	16位、单通道、超低功耗、Σ-Δ ADC，2线串口
