Overview
Features and Benefits
- Single- or Dual-Supply Operation
- Configurable Gain
- Configurable Reference Voltage
- Proven PCB layout
- Fully Assembled and Tested
Product Details
The MAX41400 evaluation kit (EV kit) provides a proven design to evaluate the MAX41400 low-power precision instrumentation amplifier with programmable gain in a nine-bump wafer-level package (WLP). The MAX41400 features internal selectable gain from 10V/V to 200V/V. The MAX41400 EV kit can set different device gain with different jumper configurations. The EV kit operates from a single supply voltage between 1.7V and 3.6V, or from dual supplies providing ±0.85V to ±1.8V.
Applications
- EKG Medical Devices
- Insulin and Infusion Pumps
- Low-Power Sensor Interface
- Pressure, Weigh, Force Sensors
- RTD Temperature Sensors
- Wearable Devices
Markets and Technologies
Applicable Parts
Documentation & Resources
-
MAX41400EVKIT: Evaluation Kit for the MAX41400 Data Sheet (Rev. 0)1/20/2021PDF384K
-
MAX41400EVKIT ODB Files - Design Files10/10/2022ZIP1M
