MAX9065

RECOMMENDED FOR NEW DESIGNS

Ultra-Small, nanoPower, Window Comparator in 4 UCSP and 5 SOT23

The Industry's Smallest Window Comparator Available in a 4-Bump UCSP

Data Sheet (Rev. 4) Product Selection Table
Part Models
4
1ku List Price
Starting From $0.49
Viewing:

Part Details

  • Tiny 1mm x 1mm 4-Bump UCSP
    • Footprint = Two 0402 Resistors
    • Also Available in 5-Pin SOT23 Package
  • Ultra-Low Power Operating Current
    • 1µA (max)
  • -0.3V to +5.5V Input Voltage Range
  • 1.0V to 5.5V VCC Range
  • 3.0V and 4.2V Trigger Points
  • -40°C to +85°C Extended Temperature Range
MAX9065
Ultra-Small, nanoPower, Window Comparator in 4 UCSP and 5 SOT23
MAX9065: Typical Operating Circuit
