MAX77962

• Evaluates the MAX77963 USB Type-C Buck-Boost Charger with Integrated FETs for 2S/3S Li-Ion Batteries
• Demonstrates 3.5V to 23V Input Operating Range
• Demonstrates Charging Up to 3.2A
• Demonstrates USB-OTG Functionality
• Demonstrates JEITA Compliance with On-Board Dummy Thermistors
• Demonstrates 8-Channel 12-Bit SAR ADC
• Demonstrates Spread Spectrum
• Fully Assembled and Tested
• I²C Serial Interface

The MAX77963 evaluation kit (EV kit) is a fully assembled and tested surface-mount printed circuit board (PCB) that evaluates the MAX77963, a 3.2A USB Type-C^® buck-boost charger.

The MAX77963 EV kit includes the IC evaluation board with an integrated I²C-communication interface and USB micro-B cable. Windows^® based graphical-user interface (GUI) software is available for use with the EV kit and can be downloaded from Analog Devices website at www.analog.com/max77963evkit. Windows 7 or newer Windows operating system is required to use the EV kit software.

• High Voltage V_BUS Range
• Short to V_BUS Protection on CC Pins
• Type-C Support and USB-PD Support
  • Mode configuration: DFP/UFP/DRP
  • Type-C rev1.3 and PD3.0 Compatible
  • Cable Orientation and Power Role Detection
  • Integrated V_CONN Switch with OCP
  • Support Try.Snk State
  • Support Audio
  • Support Debug Accessory Sink/Source Mode
  • FRS (Fast Role Swap) Initial Sink Support
  • PPS (Programmable Power Supply) Sink Support
• Support BC1.2 Legacy/Proprietary Charger Detection
  • Integrated D+/D- Switches
• MTP Memory for Storing Custom Configuration
• Moisture Detection and Corrosion Prevention
• Customization Script
• I²C Programmable Configuration
• I²C Master to Control External Charger or DC-DC Converter IC
• 9 Configurable GPIOs (GPIO6 for SID)
  • External SuperSpeed Mux/Detection/IRQ
  • EN/DISABLE External Power or FETs
• On-Board I²C Interface
• Windows 10 Compatible
• Proven PCB Layout
• Fully Assembled and Tested

The MAX77958 evaluation kit (EV kit) is a fully assembled and tested printed circuit board (PCB) that demonstrates the MAX77958 Standalone USB Type-C and Power Delivery Controller.

The EV kit enables easy evaluation of the following features:

• USB Type-C Detection/PD Communication (See Table 1 for Acronyms)
  • Power Role (Sink and Source), Data Role (UFP and DFP) detection
  • PD Adapter Detection and PD Communication
  • Integrated V_CONN Switch with OCP
  • Power/Data Role Swap
  • PPS (with PD Adapter Supporting PPS)
  • Audio and Debug Accessory Sink/Source Mode
  • Vendor Defined Message
• BC1.2 Legacy Charger Detection: SDP, CDP, DCP and DCD Timeout
• I²C Master to Control Companion IC.
• 9 Configurable GPIOs

The EV kit contains a MAX77962 charger to demonstrate the I²C master feature of the MAX77958. The MAX77962 is a buck-boost charger for 2S Li+ battery application and is capable of 3.5V to 23V input voltage, with a maximum programmable fast charging current of 3.2A.

The MAX16904 a buck converter is installed on the EV kit to provide 5V to V_CONN pin. The MAX77958 uses GPIO2 to enable the buck converter when the MAX77958 is in SOURCE Power Role.

A Micro-B USB cable is included in the package to serve as the interface from a USB port on a Windows^® PC to the slave I²C port on the MAX77958. A Windows based software provides a user-friendly interface to exercise the features of the MAX77958.

• Evaluates the MAX77962 USB Type-C Buck-Boost Charger with Integrated FETs for 2S Li-Ion Batteries
• Demonstrates 3.5V to 23V Input Operating Range
• Demonstrates Charging Up to 3.2A
• Demonstrates USB-OTG Functionality
• Demonstrates JEITA Compliance with On-Board Dummy Thermistors
• Assembled and Tested
• I²C Serial Interface

The MAX77962 evaluation kit (EV kit) is a fully assembled and tested surface-mount printed circuit board (PCB) that evaluates the MAX77962, a 3.2A USB Type-C^® buck- boost charger.

The MAX77962 EV kit includes the IC evaluation board with integrated I²C communication interface and USB micro-B cable. Windows^®-based graphical user interface (GUI) software is available for use with the EV kit and can be downloaded from Maxim’s website at MAX77962 (under the Design Resources tab). Windows 7 or newer is required to use with the EV kit GUI software.

Applications

• 2-Cell Battery Powered Devices
• USB Type-C Powered Wide-Input Charging Applications

• Evaluates the MAX77962 USB Type-C Buck-Boost Charger with Integrated FETs for 2S Li-Ion Batteries
• Demonstrates 3.5V to 23V Input Operating Range
• Demonstrates Charging Up to 3.2A
• Demonstrates USB-OTG Functionality
• Demonstrates JEITA Compliance with On-Board Dummy Thermistors
• Assembled and Tested
• I²C Serial Interface

The MAX77962 evaluation kit (EV kit) is a fully assembled and tested surface-mount printed circuit board (PCB) that evaluates the MAX77962, a 3.2A USB Type-C^® buck- boost charger.

The MAX77962 EV kit includes the IC evaluation board with integrated I²C communication interface and USB micro-B cable. Windows^®-based graphical user interface (GUI) software is available for use with the EV kit and can be downloaded from Maxim’s website at MAX77962 (under the Design Resources tab). Windows 7 or newer is required to use with the EV kit GUI software.

Applications

• 2-Cell Battery Powered Devices
• USB Type-C Powered Wide-Input Charging Applications
