MAX25249

RECOMMENDED FOR NEW DESIGNS

Four-Output Mini PMICs for Camera Applications

Industry's Smallest Power Solution for Automotive Cameras with Precision Monitoring

Data Sheet (Rev. 19) Product Selection Table
Part Models
27
1ku List Price
Starting From $2.00
Viewing:

Part Details

  • Multiple Functions for Small Size
    • 1A Synchronous High-Voltage Buck Converter
      • Input Voltage Range 5V to 36V
      • 3V to 4V, and 5V Output Voltage in 50mV Steps
    • Two Synchronous Low-Voltage Buck Converters
      • OUT2 and OUT3 Provide up to 1.2A
      • 0.8V to 3.9875V in 12.5mV Steps
    • LDO for Camera Sensor; 50dB at 1kHz
    • 2.2MHz Operation
    • Active-Low RESET Output – Push-Pull or Open-Drain
  • High Precision
    • ±1.5% Output Voltage Accuracy
    • ±1.3% OV/UV Monitoring Accuracy
  • Diagnostics and Features
    • ASIL B Compliant
    • Redundant Reference
  • Robust for the Automotive Environment
    • Current-Mode, Forced-PWM Operation
    • Overtemperature and Short-Circuit Protection
    • 3.5mm x 3.5mm 20-Pin TQFN
    • -40°C to +125°C Grade 1 Automotive Temperature Range
    • AEC-Q100 Qualified
MAX25249
Four-Output Mini PMICs for Camera Applications
MAX25249 Simplified Block Diagram
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project
Ask a Question

Documentation

Data Sheet 1

Request an NDA

Complete documentation is available upon completion of a Non-Disclosure Agreement (NDA).

Request an NDA
Learn More
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project

Evaluation Kits

MAX25249EVKIT

Evaluation Kit for the MAX25249/MAX25249B/MAX25250

Buy Now View Details

Features and Benefits

  • Meets Automotive Quality and Reliability Requirements
    • Wide Input Supply Range: 4.5V to 36V
    • -40°C to 125°C automotive temperature range
    • Overtemperature and short-circuit protection
  • High-Precision Output Voltages and ASIL Features
    • ASIL B Compliant
    • ±1.5% Accuracy for OUT1, OUT2, OUT3, and OUT4
    • ±1.3% Overvoltage- and Undervoltage-Monitoring Accuracy
  • Multiple Functions for Small Size
    • 1A Synchronous High-Voltage Buck Converter
    • Two Synchronous Low-Voltage Buck Converters (1.2A and 0.5A)
    • Precision LDO for Camera Sensor
    • 2.2 MHz Forced-PWM Operation with Spread Spectrum
    • 3.5mm x 3.5mm 20-pin TQFN package
  • Fully Assembled and Tested

Product Details

The MAX25249 evaluation kit (EV kit) is a fully assembled and tested application circuit for the MAX25249/ MAX25249B high-efficiency four-output mini PMICs designed to power camera applications. The EV kit can test each of the outputs to full load. The output voltage accuracy is ±1.5% for all outputs within the normal operation input range of +4.5V to +36V. There is a active-low RESET signal to monitor overvoltage and undervoltage with ±1.3% accuracy. The MAX25249BEVKIT# is also available, and comes pre-installed with the MAX25249BATPB/VY+ IC.

Applications

  • Front/Rear/Surround View Camera

MAX25249BEVKIT

Evaluation Kit for the MAX25249/MAX25249B/MAX25250

Buy Now View Details

Features and Benefits

  • Meets Automotive Quality and Reliability Requirements
    • Wide Input Supply Range: 4.5V to 36V
    • -40°C to 125°C automotive temperature range
    • Overtemperature and short-circuit protection
  • High-Precision Output Voltages and ASIL Features
    • ASIL B Compliant
    • ±1.5% Accuracy for OUT1, OUT2, OUT3, and OUT4
    • ±1.3% Overvoltage- and Undervoltage-Monitoring Accuracy
  • Multiple Functions for Small Size
    • 1A Synchronous High-Voltage Buck Converter
    • Two Synchronous Low-Voltage Buck Converters (1.2A and 0.5A)
    • Precision LDO for Camera Sensor
    • 2.2 MHz Forced-PWM Operation with Spread Spectrum
    • 3.5mm x 3.5mm 20-pin TQFN package
  • Fully Assembled and Tested

Product Details

The MAX25249 evaluation kit (EV kit) is a fully assembled and tested application circuit for the MAX25249/ MAX25249B high-efficiency four-output mini PMICs designed to power camera applications. The EV kit can test each of the outputs to full load. The output voltage accuracy is ±1.5% for all outputs within the normal operation input range of +4.5V to +36V. There is a active-low RESET signal to monitor overvoltage and undervoltage with ±1.3% accuracy. The MAX25249BEVKIT# is also available, and comes pre-installed with the MAX25249BATPB/VY+ IC.

Applications

  • Front/Rear/Surround View Camera
MAX25249EVKIT
Evaluation Kit for the MAX25249/MAX25249B/MAX25250
MAX25249BEVKIT
Evaluation Kit for the MAX25249/MAX25249B/MAX25250
