ADH-ABH241BS
ObsoleteAerospace, GaAs, HEMT, MMIC, Medium Power Amplifier, 50 GHz to 66 GHz
Part Details
- Output IP3: +25 dBm
- P1dB Output Power: +17 dBm
- Gain: 24 dB
- Supply Voltage: +5V
- 50 Ohm Matched Input/Output
- Die Size: 3.2 mm x 1.42 mm x 0.1 mm
- Screened in accordance with MIL-38534, Class K
The ADH-ABH241BS is a four stage GaAs HEMT MMIC Medium Power Amplifier which operates between 50 GHz and 66 GHz. The ADH-ABH241BS provides 24 dB of gain, and an output power of +17 dBm at 1dB compression from a +5V supply voltage. All bond pads and the die backside are Ti/Au metallized and the amplifier device is fully passivated for reliable operation. The ADH-ABH241BS is compatible with conventional die attach methods, as well as thermocompression and thermosonic wire bonding, making it ideal for MCM and hybrid microcircuit applications.
Applications
- Short Haul / High-Capacity Links
- Military and Space
