High Speed D/A Converters ≥30MSPS

High Speed D/A Converters ≥30MSPS

ADI high speed (≥30MSPS) DA converters include wideband radio frequency, intermediate frequency signal processing, and general-purpose baseband classes. These products are employed in wired and wireless communications, instrumentation, radar, electronic warfare, and other applications. Our portfolio of high speed DACs range from 30 MSPS to multi-GSPS with resolutions ranging from 8 bits to 16 bits. Our DACs are fully supported with complete data sheets and evaluation boards to reduce time to market and system design costs. These DACs are recommended for use with ADI’s clocking and timing products, as well as RF products and power management.

View All Parts in Subcategory

Direct Digital Synthesis (DDS)

Analog Devices’ world-leading direct digital synthesis ICs incorporate features such as on-board comparators, RAM, PLLs, mixers, and registers. ADI direct digital synthesis products provide fast acquisition, highly accurate PSK and FSK modulation or high precision tuning resolution, among other benefits. They are an ideal synthesizer solution in applications where precise or agile frequency and phase control is required, such as systems for communications, test equipment, and radar.

Fast Precision D/A Converters

For test and measurement, and HIL applications demanding both dc and ac performance, our fast precision D/A converters (DACs) enable higher speed waveform generation of up to 12.5 MSPS with 4 × oversampling with clean signal spectrums.

Mixed-Signal Front Ends (MxFE)

Scalable Software-Defined Radio Solution with 18 GHz Bandwidth

The MxFE^® products from Analog Devices offer a smart integration of RF analog-to-digital converters (ADC), RF digital-to-analog converters (DAC), on-chip digital signal processing, and clock/PLL for multichip synchronization. This allows for the elimination of discrete data converters and traditional RF front-end components to reduce size, weight, power, and cost. Integrated digital signal processing supports the transition to software-defined radio platforms, creating a highly configurable, common hardware/software platform that can be used in multiple applications across a broad array of end markets.

Quadrature Digital Up Converters (QDUC)

Analog Devices digital up/downconverters serve as the frequency translator and digital filter between data converters and DSP blocks. These products enable highly programmable and configurable receive and transmit signal chains, allowing multichannel, multicarrier radio platforms in 3G wireless base stations. They also meet the digital data conversion requirements for many other communications applications

Standard High Speed D/A Converters

Analog Devices digital-to-analog converter (DAC) portfolio provides solutions for your high speed and precision DAC applications. Thanks to complete data sheets and evaluation boards, as well as broad support among our clock and timing, RF, power management, and op amp portfolios, our DACs can help you reduce time to market and system design costs. A high speed range from 30 MSPS to multi-GSPS, 8- to 16-bit resolution, and a tiny package are just some of the features that make our industry-leading d/a converters stand out.

AD768S

PRODUCTION

Aerospace 16-Bit, 30 MSPS Digital to Analog Converter

AD9731S

PRODUCTION

Aerospace 10-Bit 170MSPS DAC

AD9776

PRODUCTION

Dual 12-Bit, 1 GSPS, Digital-to-Analog Converter

High Speed Signal Processing: Making Space in a Crowded Spectrum

The airwaves are getting crowded, and system designers are looking to untapped portions of the frequency spectrum to support higher bandwidths and millimeter wave (mmW) technologies. New capabilities and features become possible as system designers in aerospace and defense, communication infrastructure, and instrumentation learn to leverage more of the frequency spectrum and create a better user experience.

Learn More
