μModule Power Technology
μModule® power regulator technology simplifies implementation, verification, and manufacturing of complex power circuits by integrating the power function into one compact package. This system-in-package (SiP) approach streamlines the design process and reduces component count by minimizing the need to add external components.
Value and Benefits
µModule® (micromodule) regulators and DC-to-DC power products are complete system-in-package (SiP) power management solutions with integrated DC-to-DC controllers, power transistors, input and output capacitors, compensation components, and inductors within a compact, surface-mount BGA or LGA package. µModule power technology supports functions such as step-down (buck), step-down and step-up (buck-boost), battery charger, isolated converter, and LED driver.
By integrating the power function in a compact package, µModule regulator products address time and space constraints for markets that require complex power technology, ranging from industrial automation and instrumentation to aerospace and communications.
Simplifies design and implementation
Compact for space constrained applications
Minimizes the need for external components
Highly integrated solutions that reduce design time and PCB space concerns
Easy Implementation with Minimal External Components
Complete system-in-package (SiP) power management integrates the DC-to-DC controllers, power transistors, input and output capacitors, compensation components, and inductors into one device to deliver a reliable, high-efficiency, and low EMI noise power solution.
Ultrathin Package for Space Constrained Applications
The package height of the ultrathin µModule Regulator product family is 1.82mm or 1.91mm (LGA). This thin package allows placement on the backside of the PCB or under a common heat sink with digital devices such as FPGAs, GPUs, ASICs, and processors. These parts are also offered in a BGA package (0.6mm taller than LGA).
Standard Packaging Simplifies Design Layout
µModule power products are provided in BGA and LGA packages. The pad assignment of the package is uniform for easy PCB design. Both RoHS compliant and SnPb terminal finishes are available in the BGA package.
Vertical and Lateral Power Solutions for AI Systems, Data Centers
Application Interactive µModule Infographics Tool
Sort options based on your application. Use this interactive infographic to easily identify the right µModule for your design.
Function Interactive µModule Infographics Tool
Sort options based on component function. Use this interactive infographic to easily identify the right µModule for your design.
Package Interactive µModule Infographics Tool
Sort options based on component package. Use this interactive infographic to easily identify the right µModule for your design.
Manufacturing and Assembly Resources
Assembly Considerations for µModule® BGA and LGA PackagesDiscover a complete guide to:
|
µModule LGA and BGA Packaging Care and Assembly InstructionsA brief reference on handling moisture sensitivity, reflow and assembly for the LGA and BGA packages
|
µModule Regulator Printed Circuit Board Design GuidelinesThese guidelines provide insight into the process of designing the PCB layout for µModules
|
Package & Board Level ReliabilityAnalog Devices is committed to continuously improving its world-class product reliability levels and has some of the highest reliability standards in the industry
|
µModule LGA PackagesOutline drawings for LGA packages
|
µModule BGA PackagesOutline drawings and information for BGA packages
|
µModule LGA Shipping TrayShipping Tray drawings and information for LGA packages
|
µModule BGA Shipping TrayShipping Tray drawings and information for BGA packages
|
