Body Composition, Hydration, and Bioimpedance Analysis Solutions
Analog Devices’ bioimpedance analysis application solutions are powered by our high-precision, highly programmable impedance-to-digital converters, which enable intracellular detection for various bioimpedance applications with an electroimpedance spectrometry capability. An integrated digital engine enables maximum design flexibility for various applications.
Body composition analysis ranges from body fat content measurement to advanced core body hydration analysis. We provide fully integrated analog front ends that can safely excite weak electric current flows through the body and measure voltage to calculate body impedance accordingly.
Value and Benefits
Our wide range of discrete and integrated analog front ends (AFE), data conversion for BioZ, and power solutions help our customers design the next generation of state-of-the-art wearable equipment for body composition measurements. Our high-performance microprocessors, motion control, and consumable authentication RF interface solutions enhance real-time connectivity and allow for the inclusion of safety features.
Enables next generation, state-of-the-art designs
Enhances real-time connectivity
Supports integration of safety features
