Digital X-Ray Solutions
The digital x-ray system is an indispensable tool in modern screening and diagnostic imaging. It is widely used in mammography, fluoroscopy, dental, and general radiography, such as chest x-rays and more, improving patient outcomes.
In a digital x-ray system, as the radiation emitted by the x-ray tube passes through a patient’s body, it is captured by the flat panel detector and digitized to create the image for subsequent analysis and diagnosis by the radiologist.
Analog Devices’ chip-on-flex read-out ICs digitize the electrical charge captured on the panel, enabling the creation of the image through further processing.
Value and Benefits
- High-Resolution Imaging: Low-noise, high-speed ROICs deliver superior image quality across modalities.
- Radiation Dose Reduction: Low-power, integrated designs minimize patient exposure.
- Accelerated Development: Extensive product support and domain expertise reduce time to market.
- Scalable Detector Solutions: Supports static/dynamic panels with multi-gen chip-on-flex ICs.
