Overview

Features and Benefits

  • Full featured evaluation board for the ADL5580
  • Dual-supply operation
  • Easy to use interface with ACE

Product Details

The ADL5580-EVALZ evaluation board allows the manual control of the ADL5580 through the USB port on a Windows® PC via a SDP-S interface board.

Additional information on the ADL5580 is provided in the ADL5580 data sheet. Consult the ADL5580 data sheet in conjunction with the user guide when using the ADL5880-EVALZ evaluation board.

Markets and Technologies

Applicable Parts

Getting Started

EQUIPMENT NEEDED

  • +5 V and −1.8 V dc power supplies
  • System demonstration platform, EVAL-SDP-CS1Z (SDP-S)
  • Network analyzer
  • Signal generator
  • Oscilloscope with high-Z probe (option)
  • Spectrum analyzer (option)
  • Windows PC with two or more USB ports

SOFTWARE NEEDED

  • ACE software
