DC3001A-A
LTC4450 | 18V, 12A Low Quiescent Current Ideal Diode with Shutdown Mode
Top
Overview
Product Details
Demonstration Circuit 3001A-A showcases the LTC4450 ideal diode controller with an integrated low RDS(ON) MOSFET. The board includes two independent LTC4450 ideal diodes sharing a common ground and operates over a range of 0V to 18V, carrying up to 12A. The board can be set up in a diode-OR configuration by connecting the output channels together.
Markets and Technologies
Applicable Parts
Documentation & Resources
-
DC3001A - Schematic10/1/2021PDF293K
-
DC3001A-A - Demo Manual (Rev. 0)10/1/2021PDF669K
-
DC3001A-A - Design Files10/1/2021ZIP4 M
-
Ideal Diodes and Prioritizers6/8/2018PDF1 M
