MAXM17536

RECOMMENDED FOR NEW DESIGNS

4.5V to 60V, 4A High-Efficiency, DC-DC Step-Down SiP Power Module with Integrated Inductor

High-Efficiency Synchronous Buck Regulator Offers Balance of High Performance, Wide Temperature Range, and Small Size

Data Sheet (Rev. 0) Product Selection Table

Part Models: 2
1ku List Price: Starting From $17.03

Viewing:

Part Details

Reduces Design Complexity, Manufacturing Risks, and Time-to-Market
- Integrated Synchronous Step-Down DC-DC Converter
- Integrated Inductor
- Integrated FETs
- Integrated Compensation Components
Saves Board Space in Space-Constrained Applications
- Complete Integrated Step-Down Power Supply in a Single Package
- Small Profile, 9mm x 15mm x 4.32mm SiP Package
- Simplified PCB Design with Minimal External BOM Components
Offers Flexibility for Power-Design Optimization
- Wide Input-Voltage Range from 4.5V to 60V
- Output-Voltage Adjustable Range from 0.9V to 12V
- Adjustable Frequency with External Frequency Synchronization (100kHz to 2.2MHz)
- PWM, PFM, or DCM Current-Mode Control
- Programmable Soft-Start
- Auxiliary Bootstrap LDO for Improved Efficiency
- Optional Programmable EN/UVLO
Operates Reliably in Adverse Environments
- Integrated Thermal Protection
- Hiccup Mode Overload Protection
- RESET Pulled Low Output-Voltage Monitoring
- Ambient Operating Temperature Range (-40°C to +125°C)/ Junction Temperature Range (-40°C to +150°C)
- Complies with CISPR22 (EN55022) Class B Conducted and Radiated Emissions

Part Models: 2
1ku List Price: Starting From $17.03

Documentation

Data Sheet 1

MAXM17536: 4.5V to 60V, 4A High-Efficiency, DC-DC Step-Down SiP Power Module with Integrated Inductor Data Sheet (Rev.0) 11/08/2019

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAXM17536ALY#	Land Grid Array Module	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAXM17536ALY#T	Land Grid Array Module	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Tools & Simulations

EE-Sim Power® Tools 1

The EE-Sim DC-DC Converter Tool uses your requirements to quickly create a complete power design including a schematic, BOM with commercially available parts, and time and frequency domain simulations. Your customized schematic can be downloaded for further analysis in the standalone EE-Sim OASIS Simulator, featuring SIMPLIS and SIMetrix SPICE engines.

Start EE-Sim Now

SIMPLIS Models 1

MAXM17536 SIMPLIS Schematic

Evaluation Kits

Evaluation Kit for the MAXM17536 5V Output

Buy Now View Details

Features and Benefits

Wide 7V to 60V Input Range
Highly Integrated Solution with Built-In Shielded Inductor
Programmed 5V Output, Up To 4A Output Current
450kHz Switching frequency
MAXM17536 Offers High 92.1% Efficiency (V_IN = 24V, V_OUT = 5V, I_OUT = 2.5A)
All Ceramic Capacitors and Ultra-Compact Solution
Selectable PWM, DCM, and PFM Modes
Programmable 4ms Soft-Start Time and Prebias Startup
Open-Drain RESET Output Pulled Up To 5V V_CC
Programmable EN/UVLO Threshold
Provision for External Frequency Synchronization
Hiccup Overcurrent Protection (OCP)
Overtemperature Protection (OTP)
-40°C to +125°C Industrial Temperature Range
Complies with CISPR22 (EN55022) Class B Conducted and Radiated Emissions

Product Details

The Himalaya series of voltage regulator ICs and power modules enable cooler, smaller, and simpler power-supply solutions. The MAXM17536EVKIT# 5V-output evaluation kit (EV kit) is a demonstration circuit of the MAXM17536 60V, 4A high-efficiency, current-mode, synchronous stepdown DC-DC switching power module. The EV kit operates over a wide input-voltage of 7V to 60V and provides up to 4A load current with a 5V-output voltage. The EV kit is programmed to switch at a frequency of 450kHz. The module is simple to use and easily configurable with minimal external components. It features cycle-by-cycle peak current-limit protection, undervoltage lockout (EN/UVLO), and thermal shutdown.

The EV kit comes with the compact 29-pin 15mm x 9mm x 4.32mm SiP package MAXM17536 module installed and is rated to operate over the full industrial -40°C to +125°C temperature range.

The MAXM17536 module data sheet provides a complete description of the part that should be read in conjunction with this data sheet prior to operating the EV kit. For full module features, benefits and parameters, refer to the MAXM17536 data sheet.

Applications

Base-Station Point-of-Load Regulator
Distributed Supply Regulation
FPGA and DSP Point-of-Load Regulator
HVAC and Building Control Systems
Test and Measurement Equipment
