MAX77863

PRODUCTION

Complete System PMIC, Featuring 13 Regulators, 8 GPIOs, RTC, and Flexible Power Sequencing for Multicore Applications

Total Power Management IC (PMIC) for Computationally Intensive for Mobile Platforms Using SoC Application Processors

Data Sheet (Rev. 1) Product Selection Table

Part Models: 2
1ku List Price: Starting From $6.56

Viewing:

Part Details

Operates from a 2.6V to 5.5V Source
Allows for Low-Cost PCB Technology
Includes 4 DC-to-DC Step-Down Regulators
Includes 9 Low-Dropout Linear Regulators
No External MOSFETs Required
Consumes just 12μA in its Lowest-Power State
Low-Power Modes on all Regulators Reduces Power Consumption
LDOs are Stable with only the Point-of-Load Capacitor
I²C 3.0 Compatible Interface
nIRQ Interrupt Output
Eight GPIOs
Real-Time Clock (RTC)
- Backup Battery Charger
- Timing Clock Output
System Watchdog Timer
I²C Watchdog Timer
Bidirectional Reset I/O
Flexible Power Sequencer (FPS)
Thermal Shutdown

Part Models: 2
1ku List Price: Starting From $6.56

Documentation

Data Sheet 1

MAX77863: Complete System PMIC, Featuring 13 Regulators, 8 GPIOs, RTC, and Flexible Power Sequencing for Multicore Applications Data Sheet (Rev.1) 02/27/2020

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX77863AEWJ+	90-WLCSP-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX77863AEWJ+T	90-WLCSP-N/A	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Feb 2, 2021 - 2067 ASSEMBLY
		pcn_2067
MAX77863AEWJ+	PRODUCTION
MAX77863AEWJ+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Tools & Simulations

Software Development 1

MAX77863 Software GUI, 1.0.0

Evaluation Kits

Evaluation Kit for the MAX77863

Buy Now View Details

Features and Benefits

USB-to-I²C Converter Allows for Easy Communication
- Level Translator Allows for Adjusting I²C Bus Voltage from 1.8V to 3.3V
Proven PCB Reference Design and Layout
Fully Assembled and Tested

Product Details

The MAX77863 evaluation kit (EV kit) is a fully assembled and tested printed-circuit board (PCB) that demonstrates the highly-integrated MAX77863 PMIC. The MAX77863 is a complete power management IC (PMIC) for mobile devices using system-on-chip (SoC) application processors. The IC includes four buck regulators, nine low dropout linear regulators, eight GPIOs, real-time clock (RTC), backup battery charger, bidirectional reset I/O, interrupt output, and a system watchdog timer.

The EV kit uses a MAXUSB daughter board command module that provides the I²C interface to control power sequence, individual regulator output on/off, GPIOs, RTC, and setting the regulator output voltage.

Windows^®-based software provides a user-friendly graphical interface for easy evaluation.

Resources

MAX77863EVKIT ODB Files - Design Files
1.97 M
