HMC7044B

• Multi-Channel, Wideband System Development Platform Using MxFE
• Mates With Xilinx VCU118 Evaluation Board (Not Included)
• 16x RF Receive (Rx) Channels (32x Digital Rx Channels)
  • Total 16x 1.5GSPS to 4GSPS ADC
  • 48x Digital Down Converters (DDCs), Each Including Complex Numerically-Controlled Oscillators (NCOs)
  • 16x Programmable Finite Impulse Response Filters (pFIRs)
• 16x RF Transmit (Tx) Channels (32x Digital Tx Channels)
  • Total 16x 3GSPS to 12GSPS DAC
  • 48x Digital Up Converters (DUCs) , Each Including Complex Numerically-Controlled Oscillators (NCOs)
• Flexible Rx & Tx RF Front-Ends
  • Rx: Filtering, Amplification, Digital Step Attenuation for Gain Control
  • Tx: Filtering, Amplification
• On-Board Power Regulation from Single 12V Power Adapter (Included)
• Flexible Clock Distribution
  • On-Board Clock Distribution from Single External 500MHz Reference
  • Support for External Converter Clock per MxFE

• Mates to Quad-MxFE Digitizing Card & VCU118 PMOD Interface (Cable Included)
• Provides Both Individual Adjacent Channel Loopback and Combined Channel Loopback Options
• Combined Tx Channels Out Via SMA Option
• Combined Rx Channels In Via SMA Option
• On-Board Log Power Detectors With AD5592R Output To VCU118 Over PMOD
• On-Board Power Regulation from Single 12V Power Adapter (Included)

• IIO Oscilloscope GUI
• MATLAB Add-Ons & Example Scripts
• Example HDL Builds including JESD204b/JESD204c Bring-Up
• Embedded Software Solutions for Linux and Device Drivers
• MATLAB System Applications GUI

• Multi-Chip Synchronization for Power-Up Phase Determinism
• System-Level Amplitude/Phase Alignment Using NCOs
• Low-Latency ADC-to-DAC Loopback Bypassing JESD Interface
• pFIR Control for Broadband Channel-to-Channel Amplitude/Phase Alignment
• Fast-Frequency Hopping
• Calibration Board MATLAB Driver File
• FPGA Programming MATLAB Script

The Quad-MxFE System Development Platform contains four MxFE^™ software defined, direct RF sampling transceivers, as well as associated RF front-ends, clocking, and power circuitry. The target application is phased array radars, electronic warfare, and ground-based SATCOM, specifically a 16 transmit/16 receive channel direct sampling phased array at L/S/C band (0.1 GHz to ~5GHz). The Rx & Tx RF front-end has drop-in configurations that allow for customized frequency ranges, depending on the user’s application.

The Quad-MxFE System Development Platform highlights a complete system solution. It is intended as a testbed for demonstrating multi-chip synchronization as well as the implementation of system level calibrations, beamforming algorithms, and other signal processing algorithms. The system is designed to mate with a VCU118 Evaluation Board from Xilinx®, which features the Virtex® UltraScale+^™ XCVU9P FPGA, with provided reference software, HDL code, and MATLAB system-level interfacing.

In addition to the Quad-MxFE Digitizing Card, the kit also contains a 16Tx / 16Rx Calibration Board that is used to develop system-level calibration algorithms, or otherwise more easily demonstrate power-up phase determinism in situations pertinent to their own use case. The Calibration Board also allows the user to demonstrate combined-channel dynamic range, spurious, and phase noise improvements and can also be controlled via a free MATLAB add-on when connected to the PMOD interface of the VCU118.

The system can be used to enable quick time-to-market development programs for applications like:

• ADEF (Phased-Array, RADAR, EW, SATCOM)
• Communications Infrastructure (Multiband 5G and mmWave 5G)
• Electronic Test and Measurement

The AD-SYNCHRONA14-EBZ is an ideal self-contained device to use in evaluation and prototyping of applications that need a highly accurate frequency and phase-controlled source clock. It is designed around the Analog Devices AD9545 and HMC7044 and greatly simplifies clock distribution and multi-channel synchronization in complex systems. It is intended to be used by trained professionals in a laboratory environment, and not intended as an end product for commercial use. It can be taken as a complete reference design and customised as required for any end customer applications. Full design details are made available free of charge.

The AD-SYNCHRONA14-EBZ comes in a 1U mechanical form factor. Using popular industry connector SMA and TwinAX interfaces most labs will already have the needed cables.

With its internal OCXO it can operate in standalone mode or be fed from a choice of external sources, such as 3 separate high speed differential clock inputs, a 10MHz reference and 1PPS. This flexibility combined with the capability to select either of the internal VCXO options of 100MHz or 122.88MHz, gives almost unlimited choice for the frequency of interest and accuracy needed for a wide variety of application areas.

APPLICATIONS

• High accuracy reference clock distribution
• Systems clocked from a single source
• Clocks derived from 100MHz or 122.88MHz
• Phased Array Systems, RADAR, EW, SATCOMS, SDR
• Bench Equipment
• Remote controlled operation

Two evaluation options are available: AD9208-3000EBZ and AD9208-DUAL-EBZ.

• AD9208-3000 Features
• Full featured evaluation board for the AD9208-3000.
• Wide band Balun driven input.
• No external supply needed. Uses 12V-1A and 3.3V-3A supplies from FMC connector.
• Single software interface for device control and analysis through ACE.

• AD9208-DUAL Features
• Demonstration board showing multi-chip synchronization of two AD9208 ADCs using HMC7044.
• Self contained clocking for the ADCs as well as the FPGA.
• Single external 12V supply.
• Interfaces with VCU118 or similar FPGA development board with FMC+ (Vita57.4) connector.
• Uses Analog Devices’ JESD204B IP framework.
• Low SWaP high efficiency power delivery using Silent Switcher technology.
• Full software support available Analog Devices Wiki Page.

The AD9208-3000EBZ supports the AD9208-3000, a 14-bit, 3GSPS dual analog-to-digital converter (ADC). The device has an on-chip buffer and a sample-and-hold circuit designed for low power, small size, and ease of use. This device is designed support direct RF sampling analog signals of up to 5 GHz. The 3 dB bandwidth of the ADC input is greater than 9 GHz. The AD9208 is optimized for wide input bandwidth, high sampling rate, excellent linearity, and low power in a small package.

This reference design provides all of the support circuitry required to operate the ADC in its various modes and configurations. It is designed to interface directly with the ADS7-V2EBZ data capture card, allowing users to download captured data for analysis. The device control and subsequent data analyses can now be done using the ACE software package.

The AD9208-DUAL-EBZ is a demonstration board designed to show multi-chip synchronization using JESD204B subclass1 protocol. The AD9208-3000 is a 14-bit, 3GSPS dual analog-to-digital converter (ADC). This device is designed support direct RF sampling analog signals of up to 5 GHz. The 3 dB bandwidth of the ADC input is greater than 9 GHz. The AD9208 is optimized for wide input bandwidth, high sampling rate, excellent linearity, and low power in a small package. The HMC7044 is a high performance, dual-loop, integer-N jitter attenuator capable of performing reference selection and generation of ultralow phase noise frequencies for high speed data converters with either parallel or serial (JESD204B type) interfaces. The LTM8074 is a 40VIN, 1.2A continuous, 1.75A peak, step-down µModule^® (power module) regulator. The Silent Switcher architecture minimizes EMI while delivering high efficiency at frequencies up to 2.2MHz.

This reference design provides all of the support circuitry required to operate the ADC in its various modes and configurations. It is designed to easily demonstrate multi-chip synchronization using the JESD204B subclass1 protocol. The board is designed to interface directly with FPGA development boards with FMC+ (Vita57.4) connector.

• Simple power connection using USB connection and on-board LDO voltage regulators
• LDOs can be bypassed for power measurements
• AC-coupled differential SMA connectors
• SMA connectors for
  2 reference Inputs
  6 clock outputs
  1 VCXO output
• Microsoft Windows^®–based evaluation software with simple graphical user interface
• On-board PLL loop filter
• Easy access to digital input/output and diagnostic signals via input/output header (4 GPIOs)
• Status LEDs for diagnostic signals
• USB computer interface

The HMC7044 meets the requirements of multi-carrier GSM and LTE base-station designs and offers a wide range of clock management and distribution features to simplify baseband and radio card clock tree designs. The high performance dual-loop core of the HMC7044 enables the base station designer to attenuate the incoming jitter of a primary system reference clock, such as a CPRI source, with the help of the narrow-band configured first PLL loop, which disciplines an external VCXO, and generate the low phase noise, high frequency clocks with the wider-band second PLL to drive data converter sample clock inputs.

The EK1HMC7044LP10B evaluation board is a compact, easy-to-use platform for evaluating all the features of the HMC7044. A 122.88 MHz VCXO is mounted on the evaluation board to provide a complete solution. All inputs and outputs are configured as differential on the evaluation board.

Full specifications on the HMC7044 are available in the product data sheet, which should be consulted in conjunction with this user guide when working with the evaluation board.
