EVAL-AD9548
AD9548 评估板
顶部
概览
优势和特点
- Simple power connection using 6 V wall adapter and onboard switching and LDO voltage regulators
- Regulators easily bypassed for power measurements
- 8 ac-coupled SMA connectors for output
- SMA connectors for
2 differential or 4 single-ended reference input
System clock input - On-board provisions for OCXO, crystal oscillator, or crystal
- USB connection to PC
- 32-bit or 64-bit Windows-based evaluation software with simple graphical user interface
- On-board PLL loop filter
- Easy access to digital I/O and diagnostic signals via I/O header
- Status LEDs for diagnostic signals
产品详情
本页提供AD9548的评估板文档和订购信息。相关产品
文档
-
AD9548 Schematic (Rev. E)2009/9/3PDF515 K
-
UG-639: Evaluating the AD9547 and AD9548 Digital PLL Clock Synthesizers2014/4/16PDF931 kB
-
AD9547/AD9548 Evaluation Board Profile Designer2009/11/24XLS381 K
-
AD9548 Evaluation Board Layers (Rev. Rev. E)2009/9/3PDF549 K
-
AD9548 Bill of Materials (Rev. E)2009/9/3XLS58 K
-
AD9547 / AD9548: Evaluation Board Setup2024/12/12
