MAX1600

双通道CardBus和PCMCIA V_CC V_PP电源开关网络

可为2个卡槽处理1A电流，无需外部元件，微型SSOP封装

Viewing:

产品详情

Supports Two PC Card/CardBus Sockets
1A, 0.08Ω Max 3.3V VCC Switch (MAX1600 only)
1A, 0.14Ω Max 5V VCC Switch
Soft Switching for Low Inrush Surge Current
Overcurrent Protection
Overcurrent/Thermal-Fault Flag Output
Thermal Shutdown at Tj = +150ºC
Independent Internal Charge Pumps
Break-Before-Make Switching Action
10µA Max Standby Supply Current
5V and 12V Not Required for Low-RDS(ON) 3.3V Switching
Complies with PCMCIA 3V/5V Switching Specifications
Super-Small 28-Pin SSOP Package (0.2in. or 5mm wide)
Code Compatible with:
- Cirrus CL-PD67XX Family
- Databook DB86184
- Intel 82365SL (industry-standard coding)

这是最新版本的数据手册

部分模型	产品周期	描述
PCMCIA开关和驱动器 1
MAX1602	量产	单通道CardBus及PCMCIA V_CC/V_PP电源开关网络
产品 3
MAX1601		双通道CardBus和PCMCIA电源开关，带有SMBus串行接口
MAX613		双槽、PCMCIA模拟电源控制器
MAX780		双槽、PCMCIA模拟电源控制器
