Designed, Built, Tested
Board pictured here has been fully assembled and tested.

Overview

設計リソース

設計/統合ファイル

  • Schematic
  • PCB Layout
  • PCB CAD
  • Fab Package
  • BOM
設計ファイルのダウンロード 21.19 M

評価用ボード

型番に"Z"が付いているものは、RoHS対応製品です。 本回路の評価には以下の評価用ボードが必要です。

  • MAXREFDES121C# ($26.20) Isolated 24V to 3.3V 33W Power Supply
在庫確認と購入

説明

Analog Devices' power-supply experts have designed and built a series of isolated, industrial power-supply reference designs. Each of these power supplies efficiently converts 24V into useful voltage rails at a variety of power levels. Every power rail is isolated with a readily available transformer, providing quick, convenient transformer selection. Each design has been tested for load and line regulation, as well as efficiency and transient performance.

Space optimized boards are available for purchase. Each board features high-current pins that allow the design to be mounted on a PCB, like a module, further accelerating development and production runs. As with all Analog Devices reference designs, the BOM, schematics, layout files, Gerber files are all available online.

機能と利点

  • Functional insulation
  • Compact and flexible
  • Low power dissipation
  • Minimal external components
  • Robust operation in adverse industrial environments
