DC2297A-A
LT8570EDD Demo Board | Boost, 65V Power Switch, 5V ≤ VIN ≤ 10V, VOUT = 12V @ 125mA
トップへ
製品概要
製品概要
Demonstration circuits 2297A-A and 2297A-B feature the LT8570 and LT8570-1 in a boost configuration. These demo circuits demonstrate small size and low component count. Both converters are designed to convert a 5V to 10V source to 12V. Refer to the manual for maximum load current at different input voltage levels.
対象となる製品
関連資料
-
DC2297A - Schematic2015/03/09PDF29K
-
DC2297A - Demo Manual2017/03/08PDF131K
-
DC2297A - Design Files2015/03/09ZIP561K
