ADMP411

製造中止

High SPL Microphone with Bottom Port and Analog Output

データシート (Rev. 0)

Viewing:

製品の詳細

4.72 mm × 3.76 mm × 1.0 mm surface mount package
131 dB SPL acoustic overload point
Sensitivity of −46 dBV
±2 dB sensitivity tolerance
Omnidirectional response
High SNR of 62 dBA

Extended frequency response from 28 Hz to 20 kHz
Low current consumption:
< 250 µA
Single-ended analog output
High PSR of −80 dB
Compatible with Sn/Pb and Pb-free solder processes
RoHS/WEEE compliant

ドキュメント

製造中止品のデータシート 1

ADMP411: ボトム・ポートとアナログ出力の高SPLマイクロフォン (Rev.0) 04/18/2013

これは最新改訂バージョンのデータシートです。

評価用キット

ADMP411 Flex Evaluation Board

今すぐ購入詳細を表示

製品詳細

Analog Devices has sold its MEMS Microphone product line to InvenSense.
Please visit the InvenSense ADMP411 product page for all technical support and sales information.

This flex PCB includes just the ADMP411 and a bypass capacitor. The three wires allow an easy connection to the microphone’s analog output signal, VDD, and ground into your evaluation system.
