    1. EVAL-ADG5401F
      Evaluation Board & Kit
      The EVAL-ADG5401FEBZ evaluation board for the ADG5401F features one SPST switch channel and one feedback switch channel. The ADG5401F SPST switch has overvoltage detection and protection circuitry on the source pins (S and SFB) on Terminal J2 and is protected against signals up to ±60 V in the powered state and unpowered state. Figure 1 shows the EVAL-ADG5401FEBZ in a typical evaluation setup. The ADG5401F is soldered to the center of the EVALADG5401FEBZ …
      EVAL-ADG5401F

      Documentation

    2. EVAL-ADXL1003
      Evaluation Board & Kit
      The EVAL-ADXL100xZ is a simple evaluation board that allows users to quickly evaluate the performance of the ADXL1003 vibration sensor. The EVAL-ADXL100xZ is designed to mount on to a mechanical shaker and is constructed of an extra thick PCB, measuring 0.8" × 0.8". Screw holes are supplied for rigid mounting to the shaker block. This design allows users to evaluate the full performance range of the ADXL1003 vibration sensor without needing to …
      EVAL-ADXL1003

      Documentation

    3. EVAL-ADA4571
      Evaluation Board & Kit
      The EV-ADA4571RSDZ evaluation board features the ADA4571 in an end of shaft magnet configuration. The evaluation kit is composed of an ADA4571 motherboard, a magnetic stimulus on a hand turnable mount, a USB interface, and an SDP-S controller board. The required LabVIEW 2015 graphical user interface (GUI) software for Windows® is available for download from the EV-ADA4571RSDZ product page. The EV-ADA4571RSDZ evaluation board features an on-board 5 V regulator …

      Documentation

    4. EVAL-ADRF5717
      Evaluation Board & Kit
      The ADRF5717 is a 2-bit digital attenuator with 48 dB attenuation range manufactured in the silicon on insulator (SOI) process. This user guide describes the ADRF5717-EVALZ evaluation board, which is designed to simply evaluate the features and performance of the ADRF5717. A photograph of the evaluation board is shown above. For full details on the ADRF5715, see the ADRF5715 data sheet, which should be consulted in conjunction with this user guide when using …
      EVAL-ADRF5717

      Documentation

    5. EVAL-AD5753
      Evaluation Board & Kit
      This user guide explains how to use the EVAL-AD5753SDZ to evaluate the AD5753, a single-channel, 16-bit voltage and current output, digital-to-analog converter (DAC) with on-chip positive and negative dynamic power control (DPC) that minimizes package power dissipation. The EVAL-SDP-CS1Z system demonstration platform (SDP-S) board is required when using the EVAL-AD5753SDZ board. The EVAL-AD5753SDZ (see Figure 1) interfaces to the USB port of the PC …
      EVAL-AD5753

      Documentation

    6. EVAL-HMC891A
      Evaluation Board & Kit
      All RF traces are routed on Layer 1 (primary side) and the remaining three layers are ground planes that provide a solid ground for RF transmission lines. The top dielectric material is Rogers 4350, which offers low loss performance. The prepreg material in Layer 2 attaches the Isola 370HR core layer with copper traces layers above and below the core layer. Both prepreg material and the Isola 370HR core layer are used to achieve the …
      EVAL-HMC891A

      Documentation

    7. EVAL-HMC892A
      Evaluation Board & Kit
      All RF traces are routed on Layer 1 (primary side), and all other layers are ground planes that provide a solid ground for RF transmission lines. The top dielectric material is Rogers 4350, offering low loss performance. The preimpregnated (PREPREG) material in Layer 2 sticks the Isola 370HR with copper trace layers above and below together. Both the PREPREG material and the Isola 370HR core layer are used to achieve required board finish thickness.
      EVAL-HMC892A

      Documentation

    8. EVAL-HMC890A
      Evaluation Board & Kit
      All RF traces are routed on Layer 1 (primary side), and all other remaining layers are ground planes that provide a solid ground for RF transmission lines. The top dielectric material is Rogers 4350, offering low loss performance. The prepreg material in the middle sticks core layers together, which includes an Isola 370HR layer with copper traces above and below. Both the prepreg material and the Isola 370HR core layer are used to achieve required …
      EVAL-HMC890A

      Documentation

    9. EVAL-CM40X-EZLITE
      Evaluation Board & Kit
      The ADSP-CM40x mixed-signal control processor family is based on the ARM®Cortex®-M4 core and is designed for motor control and industrial applications. The ADSP-CM40x Evaluation Hardware provides a low cost hardware solution for evaluating the Analog Devices ADSP-CM40x mixed-signal control processor family, and consists of the ADSP-CM403F and ADSP-CM408F EZ-Boards™, J-LINK LITE ARM debug probe from Segger and optional probing boards .   The …
      EVAL-CM40X-EZLITE

      Documentation

    10. EVAL-ADuCM355
      Evaluation Board & Kit
      The ADuCM355 on-chip system provides the features needed to bias and to measure a range of different electrochemical sensors. The EVAL-ADuCM355QSPZ allows users to evaluate the performance of the ADuCM355 when implementing a range of different electrochemical techniques, including chronoamperometry, voltammetry, and electrochemical impedance spectroscopy (EIS). Complete specifications for the ADuCM355 are available in the ADuCM355 data sheet, which must be consulted in conjunction with the EVAL-ADuCM355QSPZ user guide when using the …
      EVAL-ADuCM355

      Documentation

    • <<
    • <
    • 1
    • 2
    • 3
    • 4
    • 5
    • >
    • >>

    Results on EngineerZone

    10,358
      Clear All Filters Icon
      We're sorry, but we couldn't find any results for your search. Please try again with a different search term and/or changing your filter criteria.
      • <<
      • <
