Overview

Features and Benefits

  • Wide 2.7V to 16V Input-Voltage Range
  • 0.5V to 5.8V Output-Voltage Range
  • Integrated Internal LDO for Bias Supply
  • Selectable Switching Frequency, OCP Threshold, DCM Operation, Voltage Loop Gain
  • Power Good (PGOOD) Indicator LED
  • Fully Assembled and Tested

Product Details

The MAX16710 evaluation kit (EV kit) is a reference platform designed for the evaluation of the MAX16710, a 10A step-down DC-DC switching regulator IC with compact WLP package. The IC operates from 2.7V to 16V input supply. It features peak current mode control, high efficiency, high-power density, and easy selection of various application scenario configurations. For more information, refer to the MAX16710 IC data sheet.

The EV kit provides a proven design to evaluate the chip and has been developed with a 6-layer PCB layout and optimized overall performance. The jumper pins, test points, and the input/output connectors are included to provide flexible and convenient use in a wide range of applications.

Applicable Parts

System Requirements

  • MAX16710 EV Kit
  • 2.7V to 16V Power Supply
  • 0A to 10A Load
  • Digital Multimeters
  • Oscilloscope and Probes
