User Guide Rev. A
1 View All

Overview

Features and Benefits

  • Full featured evaluation board for the ADL6332-EVALZA and the ADL6332-EVALZB
  • Single-supply operation
  • Easy to use interface with Analysis | Control | Evaluation (ACE) software

Product Details

The ADL6332-EVALZA and the ADL6332-EVALZB evaluation boards allow the manual control of the ADL6332 through the USB port on a Microsoft® Windows® PC through an SDP-S interface board.

The ADL6332 data sheet provides additional information on the ADL6332. Consult the data sheet in conjunction with this user guide when using the ADL6332-EVALZA and the ADL6332-EVALZB evaluation boards.

Markets and Technologies

Applicable Parts

Getting Started

  • 3.3 V DC power supply
  • EVAL-SDP-CS1Z (SDP-S)
  • Signal generator
  • Spectrum analyzer
  • Network analyzer (optional)
  • Microsoft Windows PC with a USB port
