DC2584A-A
LT4295/LT4321 Demo Board | PoE++ (71W/12V/5.5A) PD with Forward DC/DC and Ideal Diode Bridge
Top
Overview
Product Details
Demonstration circuit 2584A is an IEEE 802.3bt (Draft 2.1) compliant Power over Ethernet (PoE) Powered Device (PD). It features the LT4295 PD interface and switching regulator controller and the LT4321 PoE ideal diode bridge controller.
Markets and Technologies
Applicable Parts
Documentation & Resources
-
DC2584A - Schematic5/31/2017PDF141K
-
DC2584A - Demo Manual5/31/2017PDF933K
-
DC2584A - Design Files5/31/2017ZIP3M
