DC2541A
LTC4279 Demo Board | Single Port PoE/PoE+/LTPoE++ PSE Controller (up to 123W)
Top
Overview
Product Details
Demonstration circuit 2541A features the LTC4279, an autonomous single port Power Sourcing Equipment (PSE) controller for use in IEEE 802.3at Type 1, Type 2 and LTPoE++® compliant Power over Ethernet (PoE) systems. The LTC4279 simplifies IEEE and LTPoE++ PSE implementation, requiring only a 45-57V supply and a small number of passive support components.
Applicable Parts
Documentation & Resources
-
DC2541A - Schematic1/17/2017PDF41K
-
DC2541A - Demo Manual (Rev. A)1/17/2017PDF467K
-
DC2541A - Design Files1/17/2017ZIP1M
