HMC483

Obsolete

High IP3 Mixer SMT w/LO Amplifier, 700 - 1500 MHz

Data Sheet Product Selection Table

Part Models: 4
1ku List Price: price unavailable

Viewing:

Part Details

Input IP3: +33 dBm
Conversion Loss: 9 dB
Low LO Drive: -4 to +4 dBm

Single Positive Supply: 5V @ 50 mA
Ultra Small MSOP Package: 14.8mm²

Suggested Replacement Parts

BiCMOS Mixer w/Integrated LO Amplifier, 700 - 1500 MHz

Part Models: 4
1ku List Price: price unavailable

Documentation

Obsolete Data Sheet 1

HMC483 Data Sheet 09/11/2015
