MAX274

优势和特点

• Continuous-TIme Filter - No Clock, No Clock Noise
• Implement Butterworth, Chebyshev, Bessel and Other Filter Responses
• Lowpass, Bandpass Outputs
• Operate from a Single +5V Supply or Dual ±5V Supplies
• Design Software Available
• MAX274 Evaluation Kit Available
• 8th-Order-Four 2nd-Order Sections (MAX274)
• 4th-Order-Two 2nd-Order Sections (MAX275)
• Center-Frequency Range:
  • 150kHz for MAX274
  • 300kHz for MAX275
• Low Noise:
  • -86dB THD Typical for MAX274
  • -89dB THD Typical for MAX275
• Center-Frequency Accurate Over Temp:
  • within ±1% for MAX274
  • within ±0.9% for MAX275
