MAX1664

有源点阵液晶显示器(AMLCD)电源

低噪声集成方案，为有源矩阵TFT LCD显示器供电

Viewing:

产品详情

Integrates All Active Circuitry for Three DC-DC Converters
Ultra-Small External Components (ceramic capacitors, 2µH to 5µH inductors)
DC-DC Converters Phase-Locked to Backplane Frequency for Lowest Noise
Low Operating Voltage (down to +2.8V)
Adjustable Output Voltage from V_IN to +5.5V
Load Currents Up to 500mA
Adjustable TFT Gate Driver Output:
- Positive, V_IN to +28V
- Negative, 0 to -10V (-20V with added components)
Includes 0.35Ω Backplane Driver
1µA Shutdown Current
Power-Ready Output Signal

这是最新版本的数据手册
