DS2143

E1控制器

数据手册 (Rev. 1)

Viewing:

产品详情

E1/ISDN-PRI framing transceiver
Frames to CAS, CCS, and CRC4 formats
Parallel control port
On-board two frame elastic-store slip buffer
Extracts and inserts CAS signaling bits
Programmable output clocks for fractional E1 links, DS0 loopbacks, and drop and insert applications
On-board Sa-data-link support circuitry
FEBE E-bit detection, counting, and generation
Pin-compatible with DS2141A T1 controller
5V supply; low power (50mW) CMOS
Available in 40-pin DIP and 44-pin PLCC (DS2143Q)

参考资料

数据手册 2

DS2143-DS2143Q: E1 Controller Data Sheet (Rev.1) 11/20/1999

2853: E1控制器 Data Sheet 01/01/1900

应用笔记 1

Using RCLK in a BITS/SSU Application 02/04/2002

设计笔记 7

Telecom Application Notes Index 08/10/2001

DS2153 Programming, ETS 300-011 Remote Alarm Generation 05/15/2001

DS21Q41, DS21Q43 Interfacing to the MC68MH360 QUICC32 05/08/2001

Bit Error Rate Testing the DS314x Series of DS3/E3 Framers 09/16/2003

Interfacing to the Fractional T1 and E1 05/04/2001

Legacy T1/E1 8MHz Backplane Operation 05/29/2001

DS2141A, DS2143 Three Channel Drop and Insert 05/04/2001

这是最新版本的数据手册
