DS2141A

T1控制器

数据手册 (Rev. 1)

Viewing:

产品详情

DS1/ISDN-PRI framing transceiver
Frames to D4, ESF, and SLC-96 formats
Parallel control port
On-board, dual two-frame elastic-store slip buffers
Extracts and inserts robbed-bit signaling
Programmable output clocks
On-board FDL support circuitry
5V supply; low-power CMOS
Available in 40-pin DIP and 44-pin PLCC (DS2141Q)
Compatible with DS2186 transmit line interface, DS2187 receive line interface, DS2188 jitter attenuator, DS2290 T1 isolation stik, and DS2291 T1 long loop stik

参考资料

数据手册 2

DS2141A: T1 Controller Data Sheet (Rev.1) 11/20/1999

DS2141A: T1控制器 Data Sheet 01/01/1900

设计笔记 8

Telecom Application Notes Index 08/10/2001

DS2141A, DS2151 D4 Framing Applications 08/10/2001

DS2141A, DS2151 Alarm Set and Clear Criteria 08/10/2001

DS21Q41, DS21Q43 Interfacing to the MC68MH360 QUICC32 05/08/2001

DS2141A, DS2143 Three Channel Drop and Insert 05/04/2001

D4 Framing and Signaling 08/10/2001

Interfacing to the Fractional T1 and E1 05/04/2001

Programming and Controlling the FDL on DS2141A, DS2151 05/11/2001

技术文章 1

DS21352/552, DS2151, DS2152, DS2141A, DS21Q42 Programming SLC-96 05/31/2001

这是最新版本的数据手册
